Yokogawa A2EE2A-T S1 | Optical ESB Adapter Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (16 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Yokogawa A2EE2A-T S1: Fiber Optic ESB Bus Adapter

The Yokogawa A2EE2A-T S1 is an ESB Bus Adapter with fiber optic communication capability. This module enables long-distance data transmission in industrial control systems. It provides reliable optical connectivity for distributed control applications.

Optical Communication Specifications

  • Product Model: Yokogawa A2EE2A-T S1 ESB Bus Adapter
  • Transmission Distance: Maximum 5 kilometers per single hop connection
  • Optical Connector: LC duplex connectors compliant with IEC61754-20 standard
  • Fiber Configuration: Two-core quartz single-mode optical fiber required

Optical Performance Parameters

  • Wavelength: 1.3 micrometer (1300 nm) optical transmission wavelength
  • Optical Loss: Permissible optical loss range of 0 to 10 decibels
  • Network Topology: Supports up to 24 hops with proper system configuration
  • System Compatibility: Requires CENTUM VP R6.06 or later for full functionality

Electrical & Mechanical Specifications

  • Current Consumption: 0.5 Amperes typical operating current draw
  • Module Weight: Approximately 0.25 kilograms (main body only)
  • Connection Type: Paired connection between Master and Slave modules
  • System Support: Compatible with FCU for N-IO systems via EC402 connection

Installation & Configuration

  • Use IEC61754-20 compliant LC connectors for all optical connections
  • Ensure total optical path loss remains within 0-10 dB range
  • Configure with star topology when connecting via ANT4□1 modules
  • Verify system software meets CENTUM VP R6.06 minimum requirement

Shipping Information

  • Package includes Yokogawa A2EE2A-T S1 adapter module only
  • Optical fiber cables sold separately according to application needs
  • Weight approximately 300 grams with standard protective packaging
  • Available for international shipment via major logistics carriers

FAQ

  • What is the maximum distance? 5 kilometers per single fiber hop
  • What connector type is used? LC duplex optical connectors
  • How many fiber cores are needed? Two-core single-mode fiber required
  • What is the optical wavelength? 1.3 micrometer (1300 nm) transmission
  • What current does it draw? 0.5 Amperes typical operating current
