About the Product

Allen-Bradley 1769-OB16 16-Channel Digital Output Module

24VDC Sourcing Output Module for CompactLogix & MicroLogix Systems

Provides 16 discrete outputs in a compact form factor, ideal for controlling relays, solenoids, and indicator lights in space-constrained applications.

Output Specifications

  • Channels: 16 sourcing outputs
  • Voltage: 20.4-26.4VDC
  • Current: 0.5A @60°C, 1.0A @30°C per point
  • Response: 0.1ms ON, 1.0ms OFF
  • Surge Current: 2.0A for 10ms

System Integration

  • Compatibility: CompactLogix & MicroLogix 1500
  • Power Supply: 24VDC (200mA @5V)
  • Heat Dissipation: 2.11W
  • Terminal Block: 1769-RTBN18 (included)
  • Wire Size: 22-14 AWG

Physical Details

  • Dimensions: 4.65 x 1.38 x 3.43 in
  • Weight: 0.28kg
  • Mounting: DIN rail or panel
  • Isolation: 75VDC protection
  • Slot Width: Single

Technical Specifications

Parameter Value
Output Type 24VDC sourcing
Current per Module 4.0A @60°C, 8.0A @30°C
Leakage Current 1.0mA max @26.4VDC
Voltage Drop 1.0V max @1A
Environmental 0-60°C operating temperature

Installation Guidelines

  • Maintain 50mm clearance for proper ventilation
  • Use M4 or #8 panhead screws for panel mounting
  • Observe power supply distance rating (8 modules max from supply)
  • Follow electrostatic discharge precautions
  • Power down system before installation

Typical Applications

  • Relay control circuits
  • Solenoid valve operation
  • Pilot light activation
  • Motor starter controls
  • Conveyor system components
  • Alarm/indicator systems

Package Contents

  • 1769-OB16 output module
  • 1769-RTBN18 terminal block
  • Mounting hardware
  • Installation documentation
