330908-00-15-05-02-00 | Proximity Probes Bently Nevada

Introducing the Bently Nevada 3300 NSv Proximity Probe

Key Technical Specifications

• Model Number: 330908-00-15-05-02-00 from the 3300 NSv Proximity Probe series, featuring a 3/8-24 UNF thread and miniature coaxial ClickLoc connector.
• Linear Measurement Range: Delivers a full linear range of 1.5 mm (60 mils), operating from 0.25 mm to 1.75 mm from the target surface.
• Incremental Scale Factor (ISF): Provides standard sensitivity of 7.87 V/mm (200 mV/mil), including interchangeability error for consistent readings across installations.
• Frequency Response: Maintains typical response from 0 to 10 kHz (+0, -3 dB) with up to 305 meters of field wiring, supporting comprehensive dynamic analysis.
• Temperature Tolerance: Operates reliably in extreme environments from -52°C to +177°C (-62°F to +351°F), with a PPS tip and 304 stainless steel case.
• Electrical Characteristics: Features probe DC resistance of 4.0 ± 0.5 ohms for the 0.5m length, ensuring excellent signal integrity and system compatibility.
• Target Size Requirements: Functions with minimum flat target diameter of 8.9 mm (0.35 in), with 13 mm (0.5 in) recommended for optimal scale factor stability.

Frequently Asked Questions (FAQ)

• What is the total length of this specific probe configuration?
  This model features a total length option of 0.5 meters (20 inches), including the integrated cable and ClickLoc connector assembly.
• Can I use this probe with existing 3300 RAM extension cables?
  Absolutely, the 3300 NSv Proximity Probe is mechanically and electrically compatible with previous 3300 RAM proximity probe extension cables.
• What does the DC resistance value indicate for this probe?
  The probe shows DC resistance of 4.0 ± 0.5 ohms from center to outer conductor, helping you verify circuit integrity during installation and troubleshooting.
• Do you have this specific model in stock, and how quickly can you ship?
  Yes, we have 330908-00-15-05-02-00 in stock and typically dispatch orders within 5 business days via DHL, FedEx, or UPS.
• What is the recommended gap setting for optimal performance?
  The recommended gap setting for this 3300 NSv Proximity Probe is 1.0 mm (40 mils) for best linearity and measurement accuracy.
