Allen-Bradley 150-F317NZD SMC-Flex Solid State Controller

Allen-Bradley 150-F317NZD SMC-Flex Smart Motor Starter

Technical Specifications Summary

Motor Control & Protection Features

• Seven standard operating modes provide flexible starting and stopping control
• Built-in stall protection and jam detection prevent motor damage
• Comprehensive overload protection safeguards both motor and system
• SCR-based motor control in a compact, cost-effective package

Electrical Specifications & Protection

• Stand-alone power circuit with IEC rated impulse voltage of 6000 Volts
• Dielectric withstand capability of 2,200 Volts
• Designed to withstand 1800 Volt peak inverse voltage
• Protected from DV/DT voltage spikes via installed Resistor/Capacitor (RC) Snubber Network
• Control circuit operates at 100-240V AC with specific ON/OFF state voltages

Communication & Interface

• Built-in DPI communication interface with serial communication port
• Enables connection to Human-Module Interface (HMI) and various communication modules
• Easy configuration via 2-line by 16-character front LCD display
• Fixed programming keypad for straightforward setup and operation

Environmental & Physical Specifications

• Operating temperature range: -5°C to +50°C (23°F to 122°F)
• Storage temperature range: -20°C to +75°C (-4°F to 167°F)
• Shipping dimensions: 600.0 x 290.0 x 276.5 mm (HxWxD)
• Certifications: UL, CSA, and CE certified for quality assurance

Frequently Asked Questions

Q: What is the maximum motor size this starter can control?
A: The 150-F317NZD controls motors up to 250 HP at 460V AC with a 317A rating.

Q: What input voltage range does this unit accept?
A: It accepts a wide 230-690V AC, 3-phase input, making it versatile for various power systems.

Q: What communication capabilities does it have?
A: It features a built-in DPI communication interface for connecting to HMIs and communication modules.

Q: What protection features are included?
A: The starter includes stall protection, jam detection, and overload protection for complete motor safety.

Q: What certifications does this product hold?
A: It is UL, CSA, and CE certified, ensuring compliance with international standards.

Q: What is the operating temperature range?
A: It operates from -5°C to +50°C (23°F to 122°F) in open enclosure applications.

Q: How is the unit configured and programmed?
A: Configuration is easy via the front LCD display and fixed programming keypad.
