Key Features and Technical Specifications: Brand: GE Fanuc Series: Series 90-30 Model Number: IC693CBL332 Model Breakdown: IC693: GE Fanuc Series 90-30 PLC Compatible CBL: Connector Cable 332: Specific Right-Side 24-Pin 90-Degree Cable Variant Description: Right-Side Connector Cable with 90-Degree Connectors Cable Length: 2 Meters...

Specifications for IC200CHS003 General Information Brand: GE Fanuc Series: VersaMax Part Number: IC200CHS003 Product Type: Connector-style I/O Carrier Physical Specifications Dimensions: 2.63 x 5.25 inches Weight: 0.113 kg (approximately 0.25 lbs) Electrical Specifications Connector Type: 36-pin Current per Point: 2 Amps Current per Power...

GE Fanuc / Emerson IC695CPK400 – RX3i Standalone Quad-Core PAC Controller Technical Specifications Brand: GE Fanuc / Emerson Automation Series: PACSystem RX3i Part Number: IC695CPK400 Processor: 1.2 GHz AMD G Series Quad Core RAM: 64 MB Storage: 64 MB onboard, Micro SD slot for...

IC695PMM335 Motion Controller Overview Key Performance Highlights Position Loop: update every 500 μs Velocity Loop: update every 125 μs via FSSB Torque Loop: update every 62.5 μs via FSSB High‑Speed I/O Response: 50 μs MTBF: 100,000 hours Operating Temp.: -20 °C to 60 °C Built‑In I/O and Communication 4 × 24 VDC...

GE Fanuc IC695ACC650 Key Product Features: Model: IC695ACC650 Series: PACSystems RX3i Compatible with: GE Fanuc Series 90-70 Mounting Options: 7-slot, 12-slot, and 16-slot backplanes Torque Requirement: 2.5 Nm (captive screws) Grounding Capacity: 12 AWG or greater ground lug Mounting Orientation: Vertical and Horizontal supported...

IC697CPU788 Module Overview The IC697CPU788 is a single-slot CPU designed for Triple Modular Redundancy configurations, ensuring uninterrupted operation in safety-critical environments. Model & Suffix Explanation “IC697CPU” denotes the Series 90-70 CPU family, while the suffix 788 indicates hardware built for three-unit synchronization and majority-voting...

IC693ACC317 Model Breakdown Prefix: IC693 – Series identifier for GE Fanuc Series 90‑30 modules Suffix: ACC317 – Connector kit assembly number Technical Specifications Rated Voltage: 24 VDC (±10% / –20%) Average Input Current: 7.5 mA Internal Power Consumption: 5 mA Operating Temperature Range: –20 °C to +60 °C Cable...

GE Fanuc Current Expander Module Model: IC697ALG440 Product Specifications Voltage Input Range: -10 to +10 volts – Accommodates various input requirements for diverse applications. Current Input Range: 4 to 20 mA – Ideal for precise control systems requiring accurate current measurement. Calibration: Factory set...

GE Fanuc Versamax IC200PWR001 Technical Specifications Brand: GE Fanuc Output Voltage: 5 Volts DC and 3.3 Volts DC Part Number: IC200PWR001 Holdup Time: 10 Milliseconds Input Voltage: 24 Volts DC Weight: 0.24 lbs (0.11 kg) Inrush Current: 20 A at 24 VDC and 25...

GE Fanuc IC694MDL734 Positive & Negative‑Logic Output Module The IC694MDL734 delivers six versatile outputs (10.8–150 V DC) with hot‑swap capability, robust isolation and diagnostic LEDs for rapid status checks. Detailed Specifications Outputs: 6 isolated channels sourcing from positive or sinking to negative bus Voltage Range: 10.8–150 V DC (125 V DC rated)...

Comprehensive Functionality at a Glance: Model: IC694MDL758 Series: RX3i PacSystem Operating Voltage: 12/24 Volts DC (Positive Logic) Output Voltage Range: 10.2 to 28.8 VDC Switching Current per Output: 0.5 Amps Total Group Current: 8.0 Amps per group Number of Outputs: 32 (in 2 isolated...

DeviceNet Master Module - IC693DNM200 GE Fanuc Communication Speed: Supports speeds of 125K, 250K, and 500K Baud. Module Width: Compact design, single-slot module. Voltage Rating: Operates at rated voltages of 12 to 24 Volts DC with positive logic. Location: Can be installed in any...

GE Fanuc IC693MDL732 8-Point Digital I/O Module for Series 90-30 PLC Product Overview Technical Highlights Specification Value Rated Voltage 12 / 24 VDC Output Points 8 Peak Output Current 0.5 A per point Response Time (ON/OFF) Max 2 ms Inrush Current 4.78 A (10...

GE Fanuc IC693MDL733 12-24V DC 8-Point Digital Output Module Complete Model Information Series: GE Fanuc 90-30 PLCs Full Model: IC693MDL733 Product Type: Digital Output Module Output Type: Negative Logic, Current Sinking Output Voltage Range: 12V to 24V DC Outputs per Module: 8 Points Maximum...

IC693MDL751 Positive Logic 32-Point Digital Output Module Model & Suffix Tree IC693MDL751 -A Standard Version -H High-Temperature Version -V Enhanced Vibration Version Key Technical Specifications Output points: 32 Voltage range: 12 to 24 V DC (+20%, –15%) Module current draw: 21 mA @ 5 V DC Peak output current...

GE Fanuc Versamax IC200CHS102 Disconnect Expansion Base Industrial expansion base with field disconnect capability for Versamax systems. Safely isolate I/O modules during maintenance without rewiring. Core Specifications Brand: GE Fanuc Series: Versamax Model: IC200CHS102 Terminals: 36 box-style + 16 ancillary (Y/Z groups) Enclosure Rating:...

Product Specifications Brand: GE Fanuc Series: Versamax Part Number: IC200CHS101 Product Type: Disconnect-style Interposing I/O Terminals Compatible Cables: IC200CBL105, IC200CBL110, IC200CBL120 Dimensions: 115 x 65 x 126 mm Solid Copper Wire Size: 0.2 to 4.0 mm² Stranded Copper Wire Size: 0.2 to 2.5 mm²...

GE Fanuc Discrete Input Module IC697MDL654 Part Number: IC697MDL654 Brand: GE Fanuc Series: Series 90-70 Rated Voltage: 48 Volts DC Number of Inputs: 32 Inputs per Module Input Current: 4.7 milliAmps Input Voltage Range: -3 to 56 Volts DC Required Current: 0.3 Amps Isolation...

GE Fanuc IC200MDL140 Discrete Input Module Precise AC Signal Detection This VersaMax IC200MDL140 module monitors industrial equipment with 8 discrete inputs. Designed for 120V AC systems, it converts switch/sensor signals into PLC-readable data. Built-in power simplifies installation. Technical Specifications Brand: GE Fanuc Series: VersaMax...

🌟 Product Overview Brand: GE Fanuc Series: Versamax Part Number: IC200MDL644 Module Type: Discrete Input Module Input Points: 32 Group Count: 4 Voltage Range: 0-15 Volts DC, 5/12 Volts DC nominal User Input Current: 1.8 mA at 5 VDC, 4.9 mA at 12 VDC...
