1769-IF16V Analog Input Module - Allen-Bradley

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (13 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Allen-Bradley 1769-IF16V Compact I/O Analog Input Module

Core Specifications

Input Channels: 16 single-ended voltage inputs

Voltage Ranges: ±10V, 0-10V, 0-5V, 1-5V

Resolution: 16-bit (unipolar), 15-bit (bipolar)

Accuracy: ±0.35% at 25°C (77°F)

Conversion Rate: 16Hz/50Hz/60Hz selectable

Technical Details

Input Protection: ±30V DC maximum

Isolation: 30V DC reinforced insulation

Power Consumption: 2.4W typical

Operating Temp: 0°C to 60°C (32°F to 140°F)

Dimensions/Weight: 118x87x35mm (4.65x3.43x1.38in)/0.28kg

Industrial Applications

Process monitoring in chemical plants

Production line quality control systems

Energy management voltage monitoring

HVAC system pressure sensors

Water treatment plant flow meters

Installation Guide

DIN rail or panel mounting options

Requires 1769-PA2/PB2/PA4/PB4 power supply

Maintain 50mm clearance for ventilation

Use shielded cable (Belden 8761 recommended)

Maximum 8 modules from power supply

Compatibility

CompactLogix control systems

MicroLogix 1500 controllers

1769 series expansion modules

Studio 5000 programming software

RSLogix 5000 configuration

Package Includes

1769-IF16V analog input module

Removable terminal block

Mounting brackets

Installation documentation
