MTL4544 Dual-Channel HART Transmitter Isolator Dual-Channel Signal Conditioning for Hazardous Areas The MTL4544 provides two independent isolation channels for 2-wire or 3-wire 4-20mA/HART transmitters in Zone 0/Div. 1 hazardous locations. This intrinsically safe solution delivers 16.5V transmitter power while maintaining full HART communication capability....

Dual-Channel Current Sink for Hazardous Areas The MTL4544S provides two independent current sink channels for 4-wire transmitters in explosive environments. This intrinsically safe interface supports 24V sources while maintaining Zone 0 safety standards. Key Advantages Dual-channel design for multi-point monitoring 600Ω current sink capacity...

Hazardous Area Signal Isolator with HART Support The MTL4541B safely powers 2/3-wire transmitters in explosive areas while repeating 4-20mA signals to safe zones. This intrinsically safe barrier maintains HART communication for smart instrumentation. Core Capabilities Powers Zone 0/Div.1 transmitters with 16.5V@20mA Bi-directional HART signal...

Product Introduction The MTL4045C safely repeats 4-20mA signals in hazardous areas. This isolator drives I/P converters or loads up to 800Ω with 16V output capability. Its floating input/output circuits ensure reliable operation in Zone 0/Div.1 locations. Key Features Single-channel 4-20mA signal repeater for hazardous...

MTL5074 Smart Temperature Transmitter Hazardous Area to 4-20mA Converter Key Benefit: Converts thermocouple/RTD signals to isolated 4-20mA with software-configurable linearization for Zone 0/Div1 areas Core Specifications Input Types J/K/T/E/R/S/B/N thermocouples2/3/4-wire RTDs (100Ω @0°C) Accuracy ±0.05% or ±15μV (TC)±80mΩ (RTD)±11μA (output) Temperature Range -75mV to...

MTL5541S Repeater Power Supply Isolator Core Functionality DIN-rail mounted isolator for precise signal transfer in hazardous areas. Provides safe power to transmitters with minimal signal distortion. Key Specifications • Input/Output: 1 channel analog (0-24mA) • Ripple: <50µA peak-to-peak • Accuracy: ±15µA at 20°C •...

MTL5541 Repeater Power Supply for Hazardous Areas Essential Protection The MTL5541 safely transfers signals from Zone 0 hazardous areas. It provides clean power to transmitters while maintaining signal integrity. Precision Performance Transfer accuracy: ±15μA at 20°C Temperature stability: <0.8μA/°C drift Fast response: 50μs to...

MTL5514D - Safe Industrial Switching for Hazardous Areas Reliable Sensor Interface The MTL5514D connects hazardous area sensors to control systems. It works with switches and proximity detectors in explosive environments. Two relay outputs provide safe area control. Key Technical Specs Input channels: 1 (NAMUR...

MTL5511 Switch/Proximity Detector Interface Overview The MTL5511 safely connects hazardous-area sensors to control systems. This interface module works with NAMUR-compliant devices in explosive environments. It provides reliable signal conversion between Zone 0 and safe areas. Key Features Approved for use in hazardous locations Compact...

MTL5573 Temperature Transmitter for Hazardous Areas Core Specifications Input Channels 1 channel (Zone 0, IIC, Div.1 Groups A-D) Sensor Types Thermocouples & RTDs Output Signal 4-20mA into 600Ω max Technical Parameters RTD Excitation 200μA nominal CJC Accuracy ≤1.0°C error Noise Rejection 120dB CMRR /...
