31000-00-00-00-000-00-00 Proximity Probe Housing Bently Nevada

Bently Nevada 31000 Proximity Probe Housing Assembly

Technical Specifications

• Brand and Model: Bently Nevada 31000-00-00-00-000-00-00
• Probe Option: 00 = Probe not required
• Probe Cable Length: 00 = Probe cable not required
• Standoff Adapter: 00 = No standoff adapter
• Probe Penetration: 000 = No probe sleeve
• Fittings Option: 00 = Without fittings
• Mounting Thread: 00 = No outer sleeve, retainer, or retaining nut
• Country of Origin: Made in U.S.A.

Environmental Ratings and Certifications

• Protection Ratings: Type 4X certified by CSA and IP66 verified per SC115582-1
• Hazardous Area Compliance: CENELEC EN50014 for electrostatic dissipation in plastic materials
• Operating Temperature: -51°C to +105°C (-60°F to +221°F)
• Impact Resistance: Withstands 4 Joule impacts at -39°C and 115°C; 7 Joule at ambient temperature
• Housing Strength: Supports 912 N (205 lb) placed 38 mm from the unsupported end

Materials and Construction

• Housing Material: Glass-reinforced Polyphenylene Sulfide (PPS) thermoplastic with conductive fibers
• Sleeve and Retaining Chain: AISI 304 stainless steel
• Outer Sleeve and Exterior Screws: AISI 303 stainless steel
• O-Ring Material: Neoprene®
• Recommended Torque: 29.4 N·m (260 in·lb) for retaining nut
• Weight: 1.2 kg (2.6 lb) typical

Frequently Asked Questions

• Is the 31000 housing suitable for explosion-proof applications?
  No, the 31000 provides environmental protection only. Use CA21000 or CA24701 housings for explosion-proof requirements.
• Can I use the 31000 with probes other than 3300 XL 8 mm?
  The sealing design specifically works with 3300 XL 8 mm probes for optimal pressure sealing performance.
• What is the maximum probe penetration this housing supports?
  This configuration uses 000 penetration, meaning no probe sleeve is included. Penetration options range up to 30 inches.
• Does the housing come with mounting threads?
  This version uses 00 mounting thread, meaning no outer sleeve, retainer, or retaining nut is included. Select options with mounting threads for installation.
• How does the seal grip accommodate different cable sizes?
  This fittings option includes no seal grip or grommets. The 03 fittings option provides three grommets for cable sizes from 1/8 to 3/8 inches.
