Technical Specifications for 1756-TBCH General Information ℹ️ Brand: Allen-Bradley Part Number: 1756-TBCH Series: ControlLogix Module Type: Terminal Block Connection Details 🔗 Clamp Type: Screw-Clamp Pins: 36-Pin Connection Screw Torque: 0.5 Nm (4.4 lb/in) Single Wire Connection: 0.33 to 2.1 mm² (22…14 AWG) Double Wire...
-
Allen-Bradley 5094-RTB32V 32-Point Terminal Block Key Technical Data Number of inputs: 32 points I/O current rating: 2 Amps at 32V DC Sensor power: 10 Amps at 18-32V DC Isolation voltage: 250 Volts continuous Wire size: 14 to 22 AWG Copper wire only Weight: 202...
-
Technical Specifications Brand: ABB Model Number: 3BSC840157R1 Model: TU891 Mounting Type: Horizontal Voltage: 24 V Channels: 8 Current per Channel: Maximum 2 A Power Supply Connector Wire Size: 0.25 – 2.5 mm² (24 – 14 AWG) Process Connector Wire Size (Solid): 0.2 – 4...
-
🛠 Technical Specifications Product Information Parameter Specification Brand ABB Model 3BSE013231R1 Product Type Compact Terminal Block Series TU811V1 Channel Count 8 Connection Type Terminal block Operating Voltage 250 V I/O Compatibility DI820, DI821, DO820, DO821 Mounting Orientation Horizontal and vertical 🛠 Environmental and Compliance...
-
✨ Technical Specifications 📌 Brand: ABB 📌 Model: TU851 📌 ID: 3BSE068782R1 ✨ Electrical Specifications 🔌 Voltage: 250 V 🔌 Channels: 16 (Single I/O) ⚡ Max Current per I/O Channel: 3 A 🔧 Mounting Type: DIN rail, both directions ⚡ Dielectric Test Voltage: 2000...
-
Product Overview Brand: ABB ID: 3BSE013237R1 Model: TU836V1 Technical Specifications 🔌 Voltage: 250V 📊 Channels: 8 I/O channels 🔄 Mounting Orientation: Bidirectional 🌡️ Mounting Temperature Range: Up to 55°C (131°F) 🔌 I/O Compatibility: Compatible with DO820 and DO821 modules 🔗 Number of Process Connections:...
-
🌟 Technical Specifications 🌟 🔹 Brand: ABB 🔹 Model: 3BSE008572R1 TU838 🔹 Series: Extended I/O Terminal Block ⚡ I/O Features and Specifications ⚡ 🔸 Channels: 16 I/O channels, up to 40 process connections 🔸 Max Current per I/O channel: 3 A 🔸 Maximum Current...
-
Product Overview Brand: ABB Model: TU844 Series: Advant AC800M / 800xA Article Number: 3BSE021445R1 Type: Redundant Technical Specifications 🔌 Channels: 8 🔌 Connection Type: Terminal block ⚡ Process Power: 20 V (0V for field signals) ⚡ Voltage: 50 V 🌡️ Max Ambient Temperature: 55°C...
-
Technical Specifications Brand: ABB Model: TU850 ID: 3BSE050930R1 I/O Channels: 16 Voltage: 50 V DC Mounting Orientation: Dual direction mounting support Max Ambient Temperature: 55°C (131°F) Pollution Degree: Degree 2 (IEC 60664-1) Approvals Temperature Range: 5°C to +55°C (41°F to 131°F) Current Limiting Protection:...
-
✨ Technical Specifications 📌 Brand: ABB 📌 Model: TU890 📌 Article Number: 3BSC690075R1 📌 Type: Compact Module Terminal Unit (MTU) ✨ Electrical Specifications 🔌 Channels: 8 🔌 Connection: Terminal block ⚡ Voltage: 24 V DC (Max 50 V) ⚡ Current per Channel: 2 A...
-
Key Specifications and Features: Part Number: IC694ACC311 Module Type: Terminal Block (Box-Style) Terminal Count: 20 screw-type terminals Weight: 2 pounds (approx. 0.91 kg) Compatibility: Only with low-density IC694xx I/O modules Wire Gauge Support: AWG #22 to AWG #14 (solid and stranded copper wires) Wiring...
-
THERMOCOUPLE COLD JUNCTION COMPENSATION BASE GE Fanuc Field Control CHS004 IC670C Key Technical Specifications Specification Value Model Number IC670CHS004 Connection Pins 20 pins Terminal Wiring AWG 16-20 Terminal Torque 4.5 lb-in Maximum Current 10 Amps Compatible Modules Thermocouple I/O Modules Number of Modules Supported...
-
Technical Parameters Model: IC670CHS001 Number of Terminals: 37 Wire Size Range: AWG #14 (2.1 mm²) to AWG #22 (0.35 mm²) Max Wires per Terminal: 2 (solid or stranded copper wires) Torque for Terminal Screws: 8 in-lb (recommended) Insulation Temperature Rating: 90°C Ground Wire Size:...
-
GE Fanuc Field Control IC670CHS002 I/O Base Box Style Terminal Block Technical Parameters Model: IC670CHS002 Number of Terminals: 37 Wire Connection: One AWG #14 (2.1 mm²) or two AWG #18 (0.86 mm²) to AWG #22 (0.35 mm²) wires per terminal Terminal Torque: 4.5 in-lb...
-
GE Fanuc IC670CHS003 I/O Terminal Block - Connector Style for Field Control Systems Key Technical Specifications Model Number: IC670CHS003 Type: I/O Terminal Block with wire-to-board connectors Number of Terminals: 20 Wire Gauge: AWB 16 to 20 Terminal Torque: 4.5 lb-in Max Current per Terminal:...
-
I/O Base Barrier Style Hot Insertion Terminal Block GE Fanuc Field Control IC670CHS101 Key Technical Specifications Parameter Value Model Number IC670CHS101 Number of Terminals 37 Terminal Wiring AWG 14-22 Terminal Torque 4.5 lb-in Max Current per Terminal 10 Amps Modules Supported 2 modules per...
-
GE Fanuc IC694TBS032 Spring Terminal Block Technical Details: Brand: GE Fanuc Product Type: Spring-style High-Density Terminal Block Total Terminals: 36 Torque Requirement: 7 lb-in Wire Gauge Supported: 14 AWG to 28 AWG (Solid or Stranded) Strip Wire Length: 0.31 inches (8 mm) Insulation Thickness...
-
GE Fanuc IC694TBS132 Spring-Style Terminal Block: Precision for Industrial Automation Technical Highlights at a Glance Connection Capacity: 36-pin configuration supports 14-28 AWG wires (0.5mm²–2.5mm²), with a 0.310-inch (7.87mm) wire strip length for secure, consistent terminations. Design Specifications: Features a 13mm-deep outer cover—30% deeper than...
-
🌟 Technical Specifications 🌟 🔹 Brand: ABB 🔹 Model: 3BSE035990R1 🔹 Series: TU805 🌡️ Temperature and Environmental Specifications 🌡️ 🔸 Maximum Operating Temperature: +55°C (+131°F) 🔸 Minimum Operating Temperature: 0°C (+32°F) 🔸 Storage Temperature: -40°C to +70°C (-40°F to +158°F) 🔸 Relative Humidity: 5%...
-
🔌 TU805K01 I/O Module 📝 General Information Article Number: 3BSE035990R1 Connection Type: Terminal Block Number of Channels: 16 Rated Voltage: 50 V Compatible I/O Modules: DI801, DO801 Process Connections: 2 x 2 Process Power Terminals 2 x 16 Process Power Distribution Terminals 📏 Dimensions...
