330904-04-14-10-12-05 Bently Nevada 3300 NSv Proximity Probe

330904-04-14-10-12-05 Bently Nevada 3300 NSv Proximity Probe Overview

Key Technical Specifications

• Brand & Model: Genuine Bently Nevada 3300 NSv series, part number 330904-04-14-10-12-05 with multiple international approvals.
• Sensitivity (ISF): Delivers an incremental scale factor of 7.87 V/mm (200 mV/mil) over the entire linear operating range.
• Linear Range: Offers a 1.5 mm (60 mils) linear range from 0.25 mm to 1.75 mm from the target surface.
• Frequency Response: Maintains a typical 0 to 10 kHz range (+0, -3 dB) with up to 305 meters of field wiring.
• Environmental Tolerance: Operates reliably in extreme temperatures from -52°C to +177°C (-62°F to +351°F).
• Probe Resistance: Features a center conductor to outer conductor resistance of 4.2 ± 0.5 ohms for this 1.0-meter probe.
• Material Construction: Utilizes a Polyphenylene sulfide (PPS) probe tip and an AISI 304 stainless steel case with Viton O-ring sealing.
• Cable Type: Equipped with FluidLoc cable (option 12) for applications requiring enhanced fluid and chemical resistance.

Frequently Asked Questions (FAQ)

• Is the 330904-04-14-10-12-05 a new original Bently Nevada part?
  Yes, we supply only brand new, original Bently Nevada 3300 NSv probes in factory-sealed packaging with full traceability and warranty.
• What is the total length of this 3300 NSv probe configuration?
  The "10" in the part number 330904-04-14-10-12-05 indicates a total length of 1.0 meter (39 inches).
• What does the -05 suffix mean on this 330904 model?
  The "-05" indicates multiple international agency approvals for this 3300 NSv probe, ensuring compliance with global certification requirements.
• What is FluidLoc cable and why is it important?
  FluidLoc cable (option 12) provides enhanced resistance to fluids and chemicals compared to standard cable, making this 330904-04-14-10-12-05 ideal for harsh industrial environments.
• What is the thread size on this Bently Nevada probe?
  This specific configuration features an M10x1 probe case thread, different from the standard M8x1 found on other 3300 NSv models.
• Do you have the 330904-04-14-10-12-05 in stock?
  Yes, we maintain good stock levels for the 330904-04-14-10-12-05 model and can ship it quickly upon order confirmation.
• How quickly can you ship this 330904 proximity probe?
  We dispatch orders within five working days using trusted couriers like DHL, FedEx, or UPS with real-time tracking.
