Leuze K-D M12W-3P-5M-PVC Angled Sensor Cable

The Leuze K-D M12W-3P-5M-PVC is a flexible 5-meter connection cable. It features a right-angled M12 connector to save space in tight panels. Perfect for connecting industrial sensors and devices reliably.

• Right-angled connector for tight installation spaces.
• Long 5-meter reach for flexible sensor placement.
• Durable PVC cable for tough factory environments.
• Secure screw locking to prevent disconnection.

Technical Specifications

Product Code: Leuze K-D M12W-3P-5M-PVC
Connector Style: M12, 3-Pin, Angled Socket (90-degree)
Cable Length: 5 meters
Jacket Material: PVC (Polyvinyl Chloride)
Wire Size: 0.34 mm² conductor cross-section
Voltage Rating: Up to 250V AC/DC
Current Capacity: 4 Amps per pin
Insulation Class: Category I (IEC 60664-1)
Connection Lock: Screw-lock, self-locking mechanism
Locking Torque: 0.6 Newton-meters (recommended)
Cable Diameter: 4.7 to 5.7 mm
Minimum Bend Radius: 10 x cable diameter
Operating Temperature: -5°C to +70°C (flexible use)
Fixed Wiring Temp: -30°C to +70°C
Color: Black

Frequently Asked Questions (FAQ)

When should I choose a right-angled M12 cable?

Choose this cable when the connector port is close to a wall or another component. The angled design prevents cable strain and saves space.

Is the 5-meter length standard?

Yes, 5 meters is a common and useful length for many machine and sensor installations, providing good flexibility.

Can this cable handle power for a small device?

Yes, with a 4A per pin rating, it can carry power and signals for typical 3-pin sensors like photoelectric switches.

How do I maintain the cable in cold temperatures?

For fixed installations, it can handle -30°C. For moving cables, avoid sharp bends below -5°C to prevent jacket cracking.

What's the advantage of the screw-lock mechanism?

The screw lock ensures a vibration-proof connection that won't shake loose, which is critical on moving machinery.
