330905-02-10-05-02-CN Bently Nevada Probe - CN Spec

Bently Nevada 330905-02-10-05-02-CN: 3300 NSv Proximity Probe

Key Technical Specifications & Performance

• We provide the 330905-02-10-05-02-CN configuration with a 0.5 meter total length and country-specific approvals. The probe operates with a linear range of 1.5 mm (60 mils), starting from 0.25 mm to 1.75 mm from the target.
• This probe delivers an Incremental Scale Factor (ISF) of 7.87 V/mm (200 mV/mil). It maintains a deviation from straight line (DSL) of less than ±0.06 mm (±2.3 mils) for accurate readings.
• It features a broad frequency response from 0 to 10 kHz (+0, -3 dB) with up to 305 meters of field wiring. The system supports axial measurements on shaft diameters down to 13 mm.
• The Bently Nevada 3300 NSv probe uses a Polyphenylene sulfide (PPS) tip with an AISI 304 stainless steel case. It operates reliably in temperatures from -52°C to +177°C (-62°F to +351°F).
• We include the miniature coaxial ClickLoc connector option with standard cable. The probe cable meets 75 Ω coaxial specifications with FEP insulation for signal integrity.

Installation Guidelines & Mechanical Data

• You should finger-tighten the probe during installation, applying a maximum torque of only 0.56 N•m (5 in•lb). This prevents damage to the sensitive tip.
• Maintain a minimum bend radius of 25.4 mm (1.0 in) for the probe cable, whether armored or not. This protects the internal wiring from stress.
• The M10x1 probe case thread requires a maximum engagement length of 15 mm. For connector-to-connector torque on the case, we recommend 11.3 N•m (100 in•lb).
• For field wiring, we recommend using a three-conductor shielded triad cable from 16 to 24 AWG. You can place the proximitor up to 305 meters from the monitor.
• The Viton O-ring in the 3300 NSv design seals differential pressure between the probe tip and case. Contact us for pressure testing if your application requires it.

Package Contents & Shipping Details

• Your order includes one Bently Nevada 330905 Series Probe in new, original factory packaging. This ensures the component arrives in perfect condition.
• You will receive the probe with the specified ClickLoc connector and standard cable attached. The package contains the sensor ready for installation.
• We ship all orders via trusted carriers including FedEx, UPS, and DHL. This ensures fast and reliable delivery to your facility worldwide.

Frequently Asked Questions (FAQ)

• Is this Bently Nevada 330905-02-10-05-02-CN probe brand new?
  Yes, we supply this 3300 NSv Proximity Probe as a brand-new unit in its original, sealed factory packaging. It is not refurbished or used.
• What is the delivery time for this probe?
  We maintain this item in stock for immediate shipment. We will dispatch your order within 5 business days after payment confirmation.
• What does the "-CN" suffix mean in the part number?
  The "-CN" option indicates country-specific agency approvals. It ensures the 330905-02-10-05-02-CN meets regional certification requirements for your location.
• What is the DC resistance of this 0.5m probe?
  For the 0.5 meter probe length, the DC resistance from the center conductor to the outer conductor is 4.0 ± 0.5 ohms. The extension cable has a center conductor resistance of 0.220 Ω/m.
• What is your return policy?
  We support a 30-day return window for this item. Please ensure the probe is in its original condition and packaging for a full refund.
