Specifikacije Opće informacije: Parametar Vrijednost 🔢 Broj dijela IC695ALG608 📦 Tip modula Analogni ulaz 🏷️ Marka GE Fanuc Ulazni kanali: Parametar Vrijednost 📡 Konfigurabilni ulazni kanali 8 jednopolnih ili 4 diferencijalna analogna ulaza 🔌 Podržani signali Ulazni signali struje i napona Rasponi ulaznih signala:...

PACSystem RX3i Analog Input Module IC695ALG628 Model Details Part Number: IC695ALG628 Platform: PACSystem RX3i HART Version: 5.0 Channels: 8 single‑ended or 4 differential Key Specifications Resolution: 24‑bit ADC with ±0.01 % linearity error Response Time: ≤ 4 ms per channel Input Ranges: ±10 V, 0–10 V, ±5 V, 0–5 V, 1–5 V;...

GE Fanuc IC695ALG704 Analog Output Module Model: IC695ALG704 is compatible with RX3i CPUs (version 3.0 or later) and installs in a single slot on the universal backplane. It supports both voltage and current output modes: Voltage output ranges: ±10 VDC and 0–10 VDC Current...

Tehničke specifikacije Model: IC695ALG708 Serija: PACSystem RX3i Raspon izlaza: 0 do 20mA, 4 do 20mA, ±10V, 0 do 10V Rezolucija izlaza: 15.9 bita za struju (0 do 20mA), 14.9 bita za napon (0 do 10V) Napajanje stražnje ploče: maksimalno 375mA pri 3.3V Raspon napona...

🛠 Tehničke specifikacije Informacije o proizvodu Parametar Specifikacija Marka GE Fanuc (Emerson Automation) Model IC695ALG808 Serija PACSystem RX3i Vrsta Izolirani analogni izlazni modul Kanali 8 Raspon izlaznog napona ±10V, 0 do +10V Raspon izlazne struje 0-20 mA, 4-20 mA Potrošnja energije ležišta 80 mA...

IC695 CBL001 Energy Pack Cable Overview Model: IC695 ‒ Suffix: CBL001 is a dedicated Energy Pack Cable designed for GE Fanuc PACSystems RX3i CPUs, ensuring seamless connection between the energy pack and CPU module. Core Specifications Length: 0.91 m (3 ft) Voltage Range: 120–240 VAC / 125 VDC...

GE Fanuc IC695CBL002 Product Highlights: Model: IC695CBL002 Cable Length: 1 meter (36 inches) Connector Type: 7-pin, keyed configuration Voltage Compatibility: 24V DC, 125V DC, 120/240V AC/DC Wiring Type: Straight-through, end-to-end Termination: Integrated termination resistor RoHS Compliance: EU Directive 2011/65/EU Operating Temperature: 0°C to 60°C...

GE Fanuc IC695CBL003 – 0.6m Energy Pack to CPU Connector Cable for RX3i PACSystems Key Technical Details: Model: IC695CBL003 Cable Length: 0.6 meters / 24 inches Voltage Compatibility: 24 VDC, 125 VDC, 120/240 VDC Operating Temperature: 0°C to 60°C (32°F to 140°F) Input/Output Type:...

Tehničke specifikacije Informacije o proizvodu: Parametar Vrijednost 📦 Broj dijela IC695CHS007 🏷️ Marka GE Fanuc (Emerson Automation) 🔧 Serija PACSystem RX3i 🏭 Proizvođač Emerson Automation (prije GE Intelligent Platforms) 🛠️ Tip Univerzalna pozadinska ploča Fizičke specifikacije: Parametar Vrijednost 📏 Dimenzije (V x Š x...

IC695CMM002 GE RX3i serijski komunikacijski modul Ključne značajke Izbor brzina prijenosa: 1200, 2400, 4800, 9600, 19.2K, 38.4K, 57.6K, 115.2K Serijski protokoli: RS-232, RS-485/422 Konektori: RJ45 Zadana kontrola protoka: Puni duplex Instalacije po stalku: Do 6 modula Zahtjevi za napajanje: 0,7 A pri 3,3 VDC,...

IC695CMM004 Overview Key Features & Specifications Dimensions: 130 mm × 44 mm × 140 mm (W × H × D) Weight: 0.25 kg MTBF: 200,000 hours Power Consumption: 0.7 A @ 3.3 VDC; 0.15 A @ 5 VDC Operating Range: 0 °C to 60 °C; Humidity 5 %–95 % non‑condensing Isolation Ratings: Port‑to‑port: 500 VDC continuous; 710 VDC for 1 min Port‑to‑backplane/frame ground: 250 VAC continuous; 1500 VAC...

IC695CPE302 Technical Data Model Prefix: IC695  Model Suffix: CPE302 Processor Speed: 1.1 GHz   Program Storage: 2 MB SRAM/Flash Discrete I/O Capacity: 16 384 bits   Analog I/O Capacity: 16 384 words Power Requirements: 1 A @ +5 VDC, 1 A @ +3.3 VDC, 0.5 A @ +24 VDC Communications: RS‑232 serial, Ethernet port, USB 2.0 Protocol Support: Modbus RTU Slave, SNP Slave, Serial I/O...

IC695CPE310 Technical Specifications Model Prefix: IC695   Model Suffix: CPE310 Processor Speed: 1.1 GHz   User Logic Memory: 10 MB Flash/SRAM Discrete I/O Capacity: 32 768 bits   Analog I/O Capacity: 32 768 words Communication Ports: 1 × Ethernet (10/100 Mbps), 1 × RS‑232, 1 × RS‑485, 1 × USB 2.0 Master Supported Protocols: SNP, Serial I/O, Modbus RTU Slave/Master Power Requirements: 1 A @ +5 VDC, 1 A...

GE Fanuc / Emerson IC695CPK330 – High-Performance RX3i CPU with Energy Pack Technical Specifications Brand: GE Fanuc / Emerson Automation Series: PACSystem RX3i Part Number: IC695CPK330 Processor: 1 GHz CPU (Clock speed: 1.6 GHz internal bus) RAM: 64 MB Non-volatile Memory: 64 MB Energy...

GE Fanuc / Emerson IC695CPU310 PACSystem RX3i Procesor Specifikacije jezgre procesora Mikroprocesor Intel Celeron M Brzina takta 300 MHz RAM memorija 10 MB Nehlapiva memorija 10 MB Stopa skeniranja 0.195 ms na 1000 instrukcija Zahtjev za napajanjem 1.25A pri 3.3V DC, 1A pri 5V...

GE Fanuc IC695CRH017 Harness Assembly – RX3i PACSystems 120/240V AC Output Interface Key Technical Highlights Part Number: IC695CRH017 Voltage Type: AC Rated Voltage: 120/240 Volts AC Line Frequency: 47 – 63 Hertz Max Operating Temperature: 60°C Output Protection: Fused, 3.15A replaceable fuses Output Quantity:...

Model Breakdown: The complete model IC695EDS001 is structured as follows: IC695: Identifies the RX3i platform series. EDS: Denotes Ethernet DNP3 Slave module. 001: Specific variant of the EDS series module. Highlighted Features and Capabilities: Supports 12,072 data points and 20,000 events for reliable, time-critical...

IC695FTB001 Key Features & Core Data Power Input: 19.2 to 28.8 Volts DC, 0.45 Amps at 24 V Output Current (5 V): 0.5 Amps max Digital Outputs: 8 outputs at 24 Volts General Inputs: 16 inputs at 24 Volts Differential I/O: 4 channels at...

Product Highlights Model: IC695HSC308 Counters: 8 configurable types (A, B, C, D, E, Z, and User-defined) Counting Range: -2,147,483,648 to +2,147,483,647 Maximum Count Rate: 1.5 MHz Inputs: 16 high-speed digital inputs Outputs: 14 digital sourcing outputs Advanced Electrical Performance Input Voltage Ranges: 4.7–5.5 VDC...

IC695LRE001 - modul serijskog bus predajnika Specifikacije: Maksimalna duljina kabela: 15 metara (50 stopa) za proširbene backplaneove 213 metara (700 stopa) za udaljene backplaneove Potrebna struja: 132 mA pri 5 V DC Učinkovita brzina prijenosa podataka: 500k bajtova u sekundi (ako proširbni bus uključuje...
