Meggitt Vibro-Meter 913-402-000-012 Proximity Measuring System

The Meggitt Vibro-Meter 913-402-000-012 provides precise proximity measurement in explosive industrial environments. This advanced system combines high-temperature capability with robust construction for demanding applications.

Product Configuration

  • Manufacturer: Meggitt Vibro-Meter
  • Model Number: 913-402-000-012/A2-E045-F0-G00
  • System Type: Proximity Measuring System
  • Environmental Rating: Explosive Atmosphere Ex i
  • Cable Length: 4.5 meters ± 450 mm

Environmental Specifications

  • Operational range: -40°C to +180°C
  • Short-term survival: +180°C to +220°C
  • Explosive zone rating: Ex i certified
  • Protection classification: IP68 rated
  • Temperature drift: <5% operating range

Physical Characteristics

  • Unit weight: 0.22 kilograms
  • Transducer diameter: 8 millimeter coil
  • Cable specification: 70 ohm coaxial
  • Cable diameter: 3.6 millimeters
  • Lightweight compact design

Mechanical Durability

  • Vibration resistance: 5g peak (10-500 Hz)
  • Shock tolerance: 15g peak acceleration
  • Shock duration: 11 millisecond half-sine
  • Robust construction: Industrial grade
  • Mechanical protection: High reliability

Material Construction

  • Transducer tip: Torlon polyamide-imide
  • Body material: AISI 316L stainless steel
  • Encapsulation: High-temperature epoxy
  • Cable covering: FEP fluorinated material
  • Connector type: Self-locking miniature coaxial

Electrical Requirements

  • Power source: IQS900 signal conditioner
  • Input type: High-frequency power supply
  • Cable impedance: 70 ohm coaxial design
  • Signal transmission: Stable performance
  • Connection security: Reliable operation

FAQ

  • Environmental rating? Ex i explosive atmosphere
  • Temperature range? -40°C to +180°C operation
  • Cable length? 4.5 meters ± 450 mm
  • Protection rating? IP68 submersible protection
  • Material construction? Torlon tip, 316L stainless steel
  • Unit weight? 0.22 kilograms total weight
