1769-OF2 100% Original Brand New Allen-Bradley

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (19 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

Informazioni sul prodotto

Allen-Bradley 1769-OF2 Analog Output Module

Key Features

  • 2-channel analog voltage/current output
  • Voltage ranges: ±10V, 0-10V, 0-5V, 1-5V DC
  • Current ranges: 0-20mA, 4-20mA
  • High resolution: 14-bit (unipolar), 15-bit (bipolar)
  • Fast response: 2.9ms step response

Technical Specifications

Resolution 14-bit (unipolar), 15-bit (bipolar)
Conversion Rate 2.5ms
Accuracy ±0.5% (voltage), ±0.35% (current)
Load Capacity ≥1kΩ (voltage), ≤500Ω (current)
Power Consumption 2.36W (max)

System Integration

  • Compatible controllers: CompactLogix, MicroLogix 1500
  • Power supply distance rating: 8 modules
  • Wire size: 22-14 AWG solid or 22-16 AWG stranded
  • Mounting: DIN rail or panel mount

Protection Features

  • Short-circuit protection (21mA max)
  • Over-voltage protection
  • Open wire detection (10ms response)
  • Field calibration not required

Package Includes

  • 1769-OF2 analog output module
  • Removable terminal block (1769-RTBN18)
  • Mounting hardware
