1746-OV16 Allen-Bradley - Modul Output DC

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (17 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Allen-Bradley 1746-OV16 Modul Output DC Sinking 16-Saluran

Spesifikasi Utama

Jenis Output: 16-saluran DC sinking

Julat Voltan: 10-50VDC (24VDC nominal)

Kapasiti Arus: 0.5A/titik @30°C

Kelajuan Suis: 0.1ms ON / 1ms OFF

Arus Lonjakan: 3A selama 10ms

Kuasa Backplane: 270mA @5VDC

Ciri-ciri Prestasi

Penarafan Suhu 30°C (86°F) 60°C (140°F)
Arus per Titik 0.5A 0.25A
Jumlah Arus Modul 8A 4A

Ciri Utama

  • Blok terminal boleh tanggal untuk pemasangan wayar mudah
  • Penunjuk status LED untuk semua saluran
  • Jatuhan voltan rendah (maks 1.2V @0.5A)
  • Keupayaan suis berkelajuan tinggi
  • Reka bentuk satu slot yang padat

Aplikasi Tipikal

• Gegelung relay dan kontaktor

• Lampu pilot dan penunjuk

• Hon dan buzzer penggera

• Kawalan motor DC kecil

• Pengaktifan injap solenoid

Nota Pemasangan

Penyerapan Haba: 7.6W jumlah (0.388W setiap titik)

Pemasangan Wayar: Gunakan wayar gred yang sesuai untuk beban arus

Perlindungan Lonjakan: Pertimbangkan perlindungan luaran untuk beban induktif

Keserasian

  • Semua pemproses SLC 500 (5/01 hingga 5/05)
  • Konfigurasi casis tetap atau modular
  • Pemasangan satu slot
  • Konfigurasi penenggelaman biasa
