140NOC77100C Ethernet/IP Module | Schneider Quantum PLC

Introducing the Schneider Electric 140NOC77100C TCP/IP Module

The 140NOC77100C is an Ethernet/IP network module for Modicon Quantum automation systems. This module provides industrial Ethernet connectivity for machine control and communication. It enables seamless integration of Quantum PLCs into modern industrial networks.

Core Technical Specifications & Performance

• Brand & Model: Schneider Electric 140NOC77100C
• Network Protocol: Industrial EtherNet/IP standard
• Transmission Speed: 10/100 Mbit/s auto-negotiating
• Connection Capacity: Supports up to 128 simultaneous connections
• Communication Services: CIP Explicit & Implicit messaging, SNMP, DHCP/BootP server
• Physical Interface: RJ45 port for 10BASE-T/100BASE-TX networks
• Cable Type: Standard twisted pair Ethernet cabling
• Module Weight: 0.761 lb (0.345 kg)

Application Support & Compatibility

• Supported Applications: Machine Control, Material Handling, Packaging, Textile Machinery
• PLC Compatibility: Compatible with all Unity CPU models
• Platform: Part of the Modicon Quantum automation platform
• Power Supply: Powered through the rack power supply
• Current Consumption: Draws 500 mA at 5V DC

Robust Design & Status Indication

• Status LEDs: Eight comprehensive LEDs for communication, link, speed, duplex/collision, module status, network status, Rx/Tx activity
• Protection Rating: IP20 enclosure for basic protection
• Operating Temperature: Functions from 0°C to 60°C (32-140°F)
• Humidity Range: 10-95% RH at 60°C without condensation
• Certifications: UL 508, CSA, FM Class 1 Div 2, cUL, ODVA, C-tick, Merchant Navy
• Package Dimensions: 12.6" L x 6.7" W x 2.0" H (32 x 17 x 5 cm)
• Shipping Weight: Package weighs 17.9 oz (507 g)

Packaging & Shipping Information

• Package Includes: One (1) 140NOC77100C TCP/IP network module
• Shipping Methods: Global shipping via FedEx, UPS, and DHL
• Country of Origin: Manufactured in France
• Product Category: Quantum Controllers, High Availability, Communication

Frequently Asked Questions (FAQ)

What is EtherNet/IP protocol?

EtherNet/IP is an industrial network protocol that uses standard Ethernet with the Common Industrial Protocol (CIP). The 140NOC77100C implements this for seamless integration.

How many devices can connect to this module?

The module supports up to 128 simultaneous connections, allowing communication with multiple devices on the industrial network.

What do the various LED indicators show?

Eight LEDs provide detailed status information including link activity, network speed, duplex mode, module status, and transmit/receive activity for easy diagnostics.

Is this module suitable for harsh environments?

With IP20 rating and industrial certifications, it's designed for controlled industrial environments but not for extreme conditions like washdown areas.

Can this module replace other communication modules?

The 140NOC77100C provides Ethernet/IP connectivity specifically. Other protocols may require different communication modules in the Quantum range.
