140XTS33200 Schneider Electric I/O Connector

Schneider Electric 140XTS33200: Intrinsically Safe I/O Connector

The Schneider Electric 140XTS33200 is a specialized I/O connector for Modicon Quantum intrinsically safe modules. This 40-pin connector provides secure field wiring connections for hazardous area applications.

Core Technical Specifications

• Brand & Model: Schneider Electric 140XTS33200
• Pin Configuration: 40-pin terminal connector
• Safety Rating: Intrinsically safe design
• Channel Count: 8 input/output channels
• Isolation: Galvanic isolation between channels
• Protection Rating: IP20 indoor use
• Terminal Color: Blue coded strip
• Net Weight: 0.15kg (0.33lb)
• Module Class: Intrinsically safe accessories

Compatibility & Applications

• Compatible Modules: 140AII33000, 140DII33000, 140DIO33000
• Additional Compatibility: 140AII33010, 140AIO33000 modules
• Industrial Applications: HVAC systems and automotive testing
• Process Industries: Boilers, furnaces, food processing
• Power Applications: Power plant instrumentation and control

Installation Features

• Easy Identification: Blue color coding for quick recognition
• Secure Connections: Reliable screw terminal design
• Space Efficient: Compact connector footprint
• Wiring Organization: Clear channel separation
• Maintenance Friendly: Accessible terminal layout

Safety & Environmental

• Electrical Safety: Galvanic isolation prevents cross-talk
• Environmental Protection: IP20 rating for indoor industrial use
• Hazardous Area Use: Designed for intrinsically safe systems
• Temperature Tolerance: Suitable for standard industrial environments
• Durability: Robust construction for repeated use

Packaging & Shipping

• Package Contents: 1 x 140XTS33200 connector unit
• Shipping Options: FedEx, UPS, DHL available
• Product Category: Connection accessories

FAQ - Frequently Asked Questions

What modules is this connector compatible with?

The 140XTS33200 works with several intrinsically safe modules including 140AII33000, 140DII33000, 140DIO33000, 140AII33010, and 140AIO33000.

What does intrinsically safe mean for connectors?

Intrinsically safe connectors prevent ignition in hazardous areas. They limit electrical energy to safe levels for flammable atmospheres.

Why is galvanic isolation important?

Galvanic isolation prevents electrical interference between channels. This ensures signal integrity and enhances system safety in measurement applications.

Can this connector be used outdoors?

No, the IP20 rating indicates indoor use only. The connector requires protection from moisture, dust, and direct weather exposure.

What industries typically use this connector?

Common applications include HVAC control, automotive testing, boiler systems, food processing plants, and power generation facilities.
