1756-IR6I Analog RTD Module Allen-Bradley

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (30 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Technical Specifications for 1756-IR6I

Basic Information

Manufacturer: Rockwell Automation

Brand: Allen-Bradley

Part Number: 1756-IR6I

Series: ControlLogix

Module Type: Analog RTD Module

Inputs: 6-Point Isolated RTD

Power and Performance

Total Backplane Power: 4.25 W

Power Dissipation (Max): 4.3 W

Thermal Dissipation: 14.66 BTU/hr

Signal Characteristics

Overvoltage Protection (Max): 24V AC/DC

Noise Rejection:

  • Normal Mode: 60 dB at 60 Hz
  • Common Mode: 120 dB @ 60 Hz, 100 dB @ 50 Hz

Calibration and Accuracy

Settling Time: <80 ms to 5% of full scale

Calibration Interval: 6 months

Offset Drift: 10 MΩ/°C

Gain Drift with Temperature:

  • Nominal: 50 ppm/°C
  • Max: 90 ppm/°C



Module Error: 0.54% of range

Physical Characteristics

Weight: 0.274 kg
