1756-M02AE Servo Analog Encoder Module Allen-Bradley

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (30 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Technical Specifications for 1756-M02AE

Basic Information

Manufacturer: Rockwell Automation

Brand: Allen-Bradley

Series: ControlLogix

Part Number: 1756-M02AE

Module Type: Servo Analog Encoder Module

Key Features

Axes per Module: Two (2)

Axes per Controller: Thirty-Two (32)

Input Type: Encoder input: Incremental AB quadrature with marker

Discrete Input Type: Optically isolated, current sinking

Operating Voltage (Discrete Input): 24VDC

Output Specifications

Servo Output Type: Analog voltage

Servo Output Resolution: 16 Bits

Thermal Dissipation: 21.2 BTU/hour

Discrete Output: Solid-state isolated relay contact

Isolation Voltage: 50 Volts Continuous

Electrical Characteristics

Operating Voltage: 24V DC (Class 2 source)

Backplane Current (24Volts): 2.5 mA

Backplane Current (5Volts): 700 mA

Current Draw (5.1 Volts): 1.2 amps

Power Dissipation: 6.2 Watts

Physical Characteristics

Weight: 0.36 KG

Enclosure: None

Removable Terminal Blocks: Yes

UPC Code: 10612598172396

New Specifications

Temperature Range: -20°C to 60°C

Humidity Range: 5% to 95% Non-Condensing

Shock Rating: 30g Operating

Vibration Rating: 10 to 500 Hz, 2g

CPU Compatibility: Requires compatible ControlLogix CPU
