1769-HSC | Compact I/O High-speed Counter Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (17 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Allen-Bradley 1769-HSC High-Speed Counter Module

Core Specifications
Input Channels 2 quadrature (ABZ) differential
Input Frequency 1 MHz
Outputs 4 physical + 12 virtual
Voltage Range 2.6-30V DC (inputs), 5-30V DC (outputs)
Current Rating 1A per point (4A max per module)

Key Features

  • 1MHz counting speed for precision applications
  • Supports incremental encoders and pulse devices
  • CompactLogix and MicroLogix 1500 compatible
  • Reinforced insulation (1200V AC tested)
  • 250ns minimum pulse width detection

Technical Details

Power Consumption 425mA @ 5V DC
Isolation 75V continuous (channel-to-system)
Operating Temp 0°C to 60°C (32°F to 140°F)
Wire Size 22-14 AWG solid / 22-16 AWG stranded

Industrial Applications

  • Production line speed monitoring
  • Conveyor belt positioning systems
  • Rotary encoder integration
  • Packaging machine counters
  • Material length measurement

Installation Notes

  • Max 4 modules from power supply
  • Use shielded twisted-pair cables
  • Do not hot-swap (remove power first)
  • 90°C rated wiring required

Package Contents

  • 1769-HSC module
  • Mounting hardware
  • Documentation
  • Quick Quotes: Receive pricing and availability fast from our dedicated customer service team.
  • Delivery: Expedited, freight, and international shipping available worldwide.
  • Warranty: NexAuto offers a 12-month warranty on all parts purchased from us, in addition to any manufacturer coverage.
  • Returns: 30-day return policy for defective or mismatched parts, ensuring peace of mind.
  • Payment: Flexible options including major credit cards, PayPal, and bank transfers.
  • Custom Calibration: Provide your specifications, and we’ll handle the rest with precision.
 View Product Details
