Allen-Bradley 1769-OF4CI 4-Channel Isolated Analog Current Output Module

Analog Output Specifications
Output Type 4-channel isolated current
Current Ranges 0-20mA or 4-20mA configurable
Resolution 16-bit (0.323µA/bit)
Accuracy ±0.35% full scale
Conversion Rate 110ms per channel
Load Capacity 0-500Ω resistive, 0.1mH inductive
Electrical Characteristics
Isolation Channel-to-channel and channel-to-bus
Power Consumption 165mA @5V DC (2.0W dissipation)
Protection Open/short circuit and overvoltage
Output Impedance <1MΩ
Nonlinearity ±0.05% full scale
System Configuration
Compatible Controllers CompactLogix, MicroLogix 1500
Network Adapters 1769-AENTR (EtherNet), 1769-ADN (DeviceNet)
Data Formats Raw, Engineering units, Scaled for PID
Power Supply 1769-PA2/PB2/PA4/PB4
Recommended Cable Belden 8761 shielded

Key Features

  • Individual channel isolation for noise immunity
  • Auto-calibration on power cycle
  • No field calibration required
  • Output clamping for safety limits
  • Compact single-slot design

Typical Applications

  • Process control valve positioning
  • Variable speed drive control
  • Analog actuator control
  • Current loop instrumentation
  • Industrial process automation

Physical Specifications

  • Dimensions: 118 × 35 × 87 mm (4.65 × 1.38 × 3.43 in)
  • Weight: 270g (0.6 lb)
  • Mounting: DIN rail or panel
  • Wire Size: 22-14 AWG solid, 22-16 AWG stranded
  • Replacement Door: 1769-RD

Environmental Ratings

  • Operating Temp: 0° to 60°C (32° to 140°F)
  • Storage Temp: -40° to 85°C (-40° to 185°F)
  • Humidity: 5-95% non-condensing
