200152-25-CN Bently Nevada Accelerometer Standard Cable

Model & Configuration Details

Base Model: 200151 - Accelerometer Interface Standard Cable, Connector on Accelerometer End Only

Complete Model: 200152-25-CN

Cable Length: 25 meters for extended installation flexibility

Coupling Nut: -CN = Country Specific, ensuring regional compatibility

Technical Specifications

Minimum Bend Radius: 73.7 mm (2.9 in) for safe cable routing without performance loss

Operating Temperature Range: -20 ºC to +100 ºC (-4 ºF to +212 ºF)

Static Temperature Endurance: Down to -55 ºC (-67 ºF) for non-flexing installations

Maximum Continuous Temperature: Up to +121 ºC (+250 ºF) without degradation

Cure Time: 24 hours for optimal moisture sealing performance

Cable Construction

Design: 4-conductor, 22 AWG with braided shield and drain wire (minimum 85% coverage) for superior EMI protection

Outer Jacket: High-durability PVC for environmental resilience

Coupling Nuts: Nickel-plated for corrosion resistance

Seal Rating: IP67 - complete protection against dust ingress and temporary water immersion

Enhanced Features with Measurable Benefits

Vibration Resistance: Supports applications subject to vibrations up to 50 g

Insulation Resistance: Greater than 1 GΩ at 500 VDC, ensuring minimal signal leakage

Connector Retention Force: Exceeds 120 N (27 lbf), preventing accidental disconnections in the field

Shield Effectiveness: Provides attenuation of external electrical noise up to 60 dB at frequencies between 30 MHz and 100 MHz
