21000-16-10-00-144-03-02 - Probe Housing Assembly

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (18 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

21000-16-10-00-144-03-02 Key Features

  • 3300 XL 8 mm probe with 1.0 m (39") cable
  • 14.4-inch probe penetration (Option D dimension)
  • Material: Aluminum body + 304 stainless steel sleeve
  • Supports 3/4-14 NPT mounting thread by default
  • Weight: 1.1 kg (2.4 lb) without fittings

Technical Specifications

Maximum Visible Probe Length: 17.0" (43.18 cm)

Total Penetration Capacity: 32.9" (83.5 cm)

Temperature Range: -50°C to +80°C

Compliance & Safety

  • CSA Certified: Type 4 enclosure
  • Hazardous Area Approval: Class 1 Div 1/2 Groups C/D
  • FCC Part 15 & RoHS 2011/65/EU compliant

Installation Notes

  • Requires sleeve support for penetrations >12" (300 mm)
  • ±0.5" (13 mm) probe adjustment range
  • Includes 3/4-14 NPT plug + reducer + cable seal grip
