21000-16-10-15-114-03-02 Proximity Housing Assembly

Proximity Probe Housing Assembly 21000-16-10-15-114-03-02
Bently Nevada's new & original proximity probe housing assembly delivers precision monitoring for industrial equipment. Factory-sealed with 12-month warranty, this explosion-proof solution meets API 670 standards for reliability.

Core Features
• 3300 XL 8 mm probe with M12 connector
• 1.0 m (39 in) high-temperature resistant cable (-50°C to +150°C)
• 1.5 in (38 mm) standoff adapter for optimal positioning
• 11.4 in penetration depth ±0.5 in adjustment range
• Dual-threaded 3/4-14 NPT mounting with IP67-rated seals

Enhanced Technical Specifications
◙ Aluminum housing with 3 mm thick 304 stainless steel protective sleeve
◙ Supports 17-32.9 in (43.18-83.5 cm) probe visibility range
◙ 1.1 kg lightweight design reduces installation stress
◙ Certified for T4 @ 80°C and T5 @ 40°C temperature operation
◙ ±0.25 mm axial vibration measurement accuracy

Certifications & Safety
✓ CSA Type 4 explosion-proof certification
✓ FCC Part 15 compliant (30-1000 MHz frequency range)
✓ RoHS 2011/65/EU compliant with 0.1% max Pb content
✓ Class I Div 1/2 & Class II Div 1/2 hazardous area approval

Installation Advantages
► Includes 3/4-14 NPT plug and 1/2-14 NPT reducer
► Three-layer cable seal grips 1/8-3/8 in diameter cables
► 0.5 μm surface finish ensures optimal O-ring sealing
► Optional 2.0 in counterbore available for confined spaces

For technical drawings or bulk order pricing:
Contact: sales@nex-auto.com

Note: Probe serial numbers visible on 15-25 mm flag labels when using penetration options C+D. Sleeve supports required for installations exceeding 300 mm (12 in) probe length.
