21000-28-10-15-039-03-02 Bently Nevada Probe Assembly

Description

Bently Nevada 21000 Proximity Probe Housing Assembly is a new, factory-sealed solution for hazardous area monitoring. Designed with an aluminum body and 304 stainless steel sleeve, it includes a reverse-mount probe, dome cover, threaded ports, and optional fittings. Certified for explosion-proof applications, it meets API 670 standards and CSA Type 4 requirements.

Technical Data

Brand: Bently Nevada
Model: 21000-28-10-15-039-03-02
Suffix Details:
- Probe Option 28: 3300 XL 8mm, hazardous area approved
- Cable Length 10: 1.0m (39 in)
- Standoff Adapter 15: 1.5in (38mm)
- Probe Penetration 039: 3.9in
- Fitting 03: Includes NPT plug, reducer, cable seal grip
- Mounting Thread 02: 3/4-14 NPT

Key Specifications

Range: 8mm probe
Accuracy: API 670 compliant
Output: Non-incendive signal (CSA certified)
Temperature: -50°C to +80°C
Weight: 1.1kg (2.4lb)

Certifications

CSA Explosion-Proof (North America)
RoHS Directive 2011/65/EU

Package Includes

1x Probe Housing Assembly
1x 3/4-14 NPT plug
1x NPT reducer
1x Cable seal grip with grommets
12-month warranty

Real-World Use

Ideal for oil refineries, gas turbines, and industrial machinery requiring vibration monitoring in explosive environments.
