21000-34-05-15-066-03-02 Bently Nevada 8mm Probe Housing

Bently Nevada 21000-34-05-15-066-03-02 8mm Proximity Probe Housing Assembly

Key Technical Specifications

• Manufacturer & Series: Bently Nevada 21000 Series housing configured for the 3300 XL 8 mm probe with connector protector.
• Probe & Cable Details: Includes a reverse mount proximity probe with a 0.5 m (20 in) integral cable and connector protector for secure signal transmission.
• Critical Dimensions: Features a 1.5 in standoff adapter and a 6.6 in probe penetration to accommodate specific machine train measurement requirements.
• Mounting & Fittings: Comes with a 3/4-14 NPT mounting thread and the complete 03 fitting option with plug, reducer, and multi-size cable seal grip.
• Enclosure Rating: Certified as a CSA Type 4 enclosure, with specific configurations rated explosion-proof for hazardous areas when ordered with CA options.
• Physical Weight: The assembly weighs approximately 1.1 kg (2.4 lb) without the conduit fittings installed.

Installation and Mechanical Details

• Housing Construction: We build this housing with an aluminum body and a 304 stainless steel sleeve for excellent corrosion resistance in harsh environments.
• Conduit Connections: The 03 fitting option provides a 3/4-14 NPT plug, a 3/4-14 to 1/2-14 NPT reducer, and a cable seal grip with grommets for cable sizes from 1/8 to 3/8 inches.
• Probe Visibility: The assembly design positions the probe so that its part number and serial number are not visible after installation, ensuring a clean exterior.
• Total Assembly Length: The maximum combined length from the housing body to the probe tip is 13.5 inches (34.3 cm), maintaining consistency across configurations.

Frequently Asked Questions (FAQ)

• What is the probe penetration length for this model?
  This 21000-34-05-15-066-03-02 features a 6.6-inch probe penetration (indicated by the "066" suffix), making it ideal for applications requiring a medium insertion depth.
• What does the 03 fitting option include?
  The 03 fitting option includes one 3/4-14 NPT plug, one 3/4-14 to 1/2-14 NPT reducer, and a cable seal grip with three sizes of grommets for maximum installation flexibility.
• What is the return policy for this item?
  We offer a 30-day return window for this item, provided it remains in its original, unopened factory condition. Verify all part numbers before installation.
• Is this housing suitable for hazardous area installations?
  While the housing includes explosion-proof fittings, only CA versions with E:00, E:01, E:02, or E:04 options carry the full CSA explosion-proof rating. This standard housing is CSA Type 4 rated.
• How quickly can you ship this proximity probe housing?
  We maintain a large inventory of Bently Nevada parts. We typically dispatch this housing within 5 days after receiving and confirming your order.
