24701-28-05-00-110-03-01 Bently Nevada Proximity Probe Housings

Compact Proximity Probe Assembly

Introducing the Bently Nevada 24701-28-05-00-110-03-01 - a specialized proximity housing with unique cast mounting design. This factory-fresh assembly ships in original packaging with comprehensive 12-month manufacturer warranty for industrial monitoring applications.

Precision Configuration

• Base Model: 24701 (Probe Housing Assembly)
• Probe Type: 28 - 3300 XL 8mm with certified connector
• Cable Length: 05 - 20 inches (0.5 meter)
• Adapter: 00 - Direct mount without standoff
• Penetration Depth: 110 - 11-inch measurement range
• Fittings: 03 - Comprehensive sealing kit
• Mounting: 01 - As-cast without threads

Robust Construction

Manufactured with 303 stainless steel body and 304 stainless steel sleeve for maximum durability. Maintains ±0.2mm tolerance across 11-inch penetration. Weighs 1.8kg (4.1lb) without fittings.

Critical dimensional specifications:
Maximum assembly clearance: 13.5 inches (34.3 cm)
Probe visibility: Not visible (P/N and S/N concealed)

Complete Package Contents

1. Sealed dome cover with precision threading
2. Dual-port conduit connection system
3. 11-inch probe sleeve for deep measurements
4. High-temperature O-ring set (3 pieces)
5. Reverse-mount proximity probe
6. Industrial-grade thread sealant
7. Fittings Kit:
8. One 3/4-14 NPT plug
9. One 3/4-14 to 1/2-14 NPT reducer
10. Cable seal grip with triple grommet sizes:
    • 1/8 to 3/16 inches
    • 1/4 to 5/16 inches
    • 5/16 to 3/8 inches
