3300 XL 8 mm Armored Probes 330141-08-90-02-05

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (35 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Bently Nevada 330141-08-90-02-05: Hazardous Area Certified 8mm Vibration Probe

Configuration Breakdown

  • 330141: 8mm armored probe body
  • 08: 0.8in (20.3mm) stainless steel case
  • 90: 9.0 meter (29.5 ft) cable length
  • 02: ClickLoc miniature coaxial connector
  • 05: CSA/ATEX/IECEx hazardous area certification

Certified Performance

  • Explosive Atmosphere Rating: ATEX Cat 1G/1D, IECEx Ex ia IIC T4 Ga/Da
  • Temperature Class: T4 (135°C surface temp) for gas environments
  • Ingress Protection: IP66 sealed against dust/liquids
  • Compliance Marks: CSA Class I Div 1, II 3G Ex ia IIC T4

Enhanced Safety Features

  • Intrinsic Safety: 250V max input voltage with 100mA current limitation
  • Barrier Compatibility: Certified for use with IS barriers > 15V/100mA
  • Static Discharge: <1nJ spark energy prevents ignition
  • Warranty: 1-year manufacturer guarantee

Precision Engineering

  • Electrical: 9.87Ω ±0.50 DC resistance at 9m length
  • Linearity: ±0.038mm (±1.5 mil) deviation over 0-45°C range
  • Humidity Resistance: <3% ASF change after 56 days at 93% RH
  • Temperature Range: -62°F to +350°F (-52°C to +177°C)
  • Quick Quotes: Receive pricing and availability fast from our dedicated customer service team.
  • Delivery: Expedited, freight, and international shipping available worldwide.
  • Warranty: NexAuto offers a 12-month warranty on all parts purchased from us, in addition to any manufacturer coverage.
  • Returns: 30-day return policy for defective or mismatched parts, ensuring peace of mind.
  • Payment: Flexible options including major credit cards, PayPal, and bank transfers.
  • Custom Calibration: Provide your specifications, and we’ll handle the rest with precision.
