3300 XL 8 mm Proximity Probes | 330101-00-07-10-02-05

Bently Nevada 3300 XL 8mm Proximity Probe – Precision Monitoring for Industrial Machinery

Key Features at a Glance

Brand Trust: Bently Nevada – 50+ years in industrial sensor innovation. Condition: Brand-new, factory-sealed packaging. Warranty: 12-month coverage (standard industrial protection). Certified Safety: CSA, ATEX, IECEx approved for hazardous zones.

Technical Specifications

Model: 3300 XL 8mm Proximity Probe (Part#: 330101-00-07-10-02-05). Measurement Range: 2mm (80 mils) linear accuracy. Precision: ±5% error (includes sensor interchangeability). Output: -1V to -17V DC (proportional to target distance). Temp Range: -51°C to +177°C (-60°F to +351°F) – extreme environment ready. Frequency Response: 0-10kHz (±0/-3 dB) for fast vibration tracking.

Suffix Explained

Each number in "330101-00-07-10-02-05" defines a feature: 00: Unthreaded length = 0.0 inches (smooth probe body). 07: Case length = 0.7 inches (compact design). 10: Cable length = 1.0m (3.3ft) – standard for most setups. 02: Connector = Mini ClickLoc (secure, easy to install). 05: Certifications = CSA/ATEX/IECEx (hazard-safe).

Installation Tips

Target Distance: Mount 0.25-2.3mm from conductive surfaces (e.g., steel). Cable Care: Bend radius >5x cable diameter; use CableLoc for stability. Proximitor Fit: Works with standard 4-hole panels – no extra tools needed.
