330100-90-02 Bently Nevada 3300 Proximitor Sensor

Manufacturer: Bently Nevada

Product Number: 330100-90-02

Product Type: 3300 Proximitor Sensor

Origin: Made in U.S.A

Certificate of Origin: Available upon request

Total Length Option: 90 - 9.0 metres (29.5 feet)

Agency Approval Option: 05 - Multiple Approvals

Weight: 0.59 kg

Unique Attributes

• Calibration: ±0.5% of full-scale range
• Cable Resistance: 55 Ohm/km
• Max Frequency Response: 150 Hz
• Operating Temperature Range: -40°C to 105°C
• Input Impedance: 10 MΩ
• Burst Pressure: 150 bar

Notes

1. All dimensions are in millimetres (inches) unless otherwise noted.
2. Standard mount 8 mm probes supplied with 17 mm or 9/16-in lock nut.
3. Standard mount 5 mm probes supplied with 13 mm or 7/16-in lock nut.
4. Reverse mount probes not available with armor, connector protector or FluidLoc® options.
5. Minimum cable bend radius is 25.4 mm (1.0 in) with or without armor.
6. Letters inside quotation marks refer to probe ordering options.
7. Stainless steel armor is supplied with FEP outer jacket.
8. FEP jacket is standard on all non-armored probes.
9. Probes ordered with 5 or 9 metre integral cables have a length tolerance of +20%, -0%.
