330101-00-84-20-02-00 Bently Nevada 3300 XL 8mm Probe

330101-00-84-20-02-00 – Bently Nevada 3300 XL 8 mm Probe (Without Armor)

• Linear Measurement Range: The probe provides a 2 mm (80 mils) linear range. It starts at 0.25 mm (10 mils) from the target. It extends up to 2.3 mm (90 mils). Output voltage spans approximately –1 to –17 Vdc.
• Recommended Gap Setting for Radial Vibration: Set the operating gap at -9 Vdc. This equals roughly 1.27 mm (50 mils). This setting ensures optimal sensitivity.
• Incremental Scale Factor (ISF) – Standard 5 or 1 Meter System: Value is 7.87 V/mm (200 mV/mil) ±5%. This includes interchangeability error. We measure over 0.25 mm (10 mils) increments across the full 80 mil range. Temperature range applies from 0°C to +45°C (+32°F to +113°F).
• ISF for Standard 9 Meter System: Scale factor equals 7.87 V/mm (200 mV/mil) ±6.5%. Conditions match the 5-meter system. This maintains accuracy with longer cables.
• Deviation from Best Fit Straight Line (DSL) – 5 or 1 Meter System: Less than ±0.025 mm (±1 mil). This holds at 0°C to +45°C (+32°F to +113°F).
• DSL for Standard 9 Meter System: Less than ±0.038 mm (±1.5 mil) under the same temperature range. Extended temperature range systems follow this same specification.
• Nominal Probe DC Resistance (RPROBE): For 2.0 meter probe length, resistance equals 7.88 ± 0.50 Ω. Measure between center conductor and outer conductor.
• Extension Cable Capacitance: Typical capacitance is 69.9 pF/m (21.3 pF/ft). This supports signal integrity over distance.
• Field Wiring Guidelines: Use 0.2 to 1.5 mm² (16 to 24 AWG) wires. We recommend a 3-conductor shielded triad cable with tinned wiring. Maximum field wiring length is 305 meters (1,000 feet) between the 3300 XL Proximitor Sensor and monitor. Check frequency response graphs for high-frequency signal rolloff.
• Probe Tip Material: Polyphenylene sulfide (PPS) provides excellent chemical resistance. This material also ensures durable encapsulation of the probe coil.
• Probe Case Material: AISI 303 or 304 stainless steel (SST) offers high strength and corrosion resistance. The larger diameter case enhances ruggedness.
• Weight per Unit Length: 323 g/m (11.4 oz). This weight indicates solid construction quality.

Frequently Asked Questions (FAQ)

• Q: Is this probe brand new and original?
  A: Yes, we provide a 330101-00-84-20-02-00 that is 100% new and original from Bently Nevada. No refurbished or counterfeit parts.
• Q: What is the exact linear range for this 3300 XL 8 mm probe?
  A: The linear range is 2 mm (80 mils). It starts at 0.25 mm (10 mils) from the target and ends at 2.3 mm (90 mils). Output voltage spans –1 to –17 Vdc.
• Q: Can I use this probe with a 9 meter extension cable?
  A: Yes. The standard 9 meter system has an ISF of 7.87 V/mm ±6.5%. The deviation remains less than ±0.038 mm within 0°C to +45°C.
• Q: What shipping methods do you offer?
  A: We ship via FedEx, UPS, and DHL. All carriers provide tracking and reliable delivery worldwide.
• Q: How long does delivery take?
  A: We dispatch all orders within 5 business days. Delivery time depends on your location and chosen carrier.
• Q: Do you have stock available?
  A: Yes, we keep the 330101-00-84-20-02-00 in stock. We can ship promptly after order confirmation.
• Q: What is the return policy?
  A: We accept returns within 30 days of delivery. Items must be unused and in original condition.
• Q: What temperature range can the probe tip withstand for extended range version?
  A: The extended temperature range probe tip handles -52°C to +218°C (-62°F to +425°F). Cable and connector handle -51°C to +260°C.
• Q: Does the probe resist humidity?
  A: Yes. The ASF changes less than 3% after 56 days at 93% relative humidity per IEC 68 2 3.
• Q: Can I order the FluidLoc option?
  A: This specific model 330101-00-84-20-02-00 does not include FluidLoc. Please contact us for custom orders with FluidLoc.
