330130-030-01-00 Bently Nevada | Extension Cables

Overview:

The Bently Nevada 330130-030-01-00 is a critical component of the 3300 XL 8mm Proximity Transducer System, designed for non-contact vibration monitoring in industrial environments. This system is made in the U.S.A and is compatible with 3300-series 5mm, 3300 8mm, and 3300 XL 8mm Proximity Probes. The system offers 3.0-meter (9.8-foot) armored cable for enhanced durability and signal transmission, utilizing corrosion-resistant gold-plated ClickLoc connectors for secure and reliable connections. With a power range of -17.5 Vdc to -26 Vdc (or -23 Vdc to -26 Vdc with barriers), the system ensures optimal performance with minimal voltage change. The Certificate of Origin (COO) can be added upon request.

Technical Specifications:

• Brand: Bently Nevada
• Model: 330130-030-01-00
• Product Type: 3300 XL 8mm Proximity Transducer System
• Cable Length: 030 = 3.0 meters (9.8 feet)
• Cable Option: 01 = Armored cable for superior protection
• Power Requirements:
  • -17.5 Vdc to -26 Vdc without barriers at 12 mA maximum consumption
  • -23 Vdc to -26 Vdc with barriers
• Supply Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage
• Output Resistance: 50 Ohm
• Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Connectors: Corrosion-resistant, gold-plated ClickLoc connectors for probe, extension cable, and Proximitor sensor
• Agency Approval Option: 00 = Not required
• Application: Vibration monitoring for rotating machinery in industrial applications.
