330141-08-90-11-05 | 3300 XL 8 mm Armored Probes

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (37 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Bently Nevada 330141-08-90-11-05: Hazardous Area FluidSeal™ Probe

Configuration Breakdown

  • 330141: 8mm armored probe with 0.8in SST case
  • 90: 9.0 meter cable length
  • 11: FluidLoc™ cable + ClickLoc connector with protector
  • 05: CSA/ATEX/IECEx hazardous area certification

Dual-Protection Technology

  • FluidLock™ Barrier: Triple-layer cable prevents fluid migration at 75psi internal pressure
  • Explosion Protection: ATEX/IECEx Ex ia IIC T4 Ga/Da certified
  • Connector Shield: Zinc-nickel plated protector withstands 50G impacts
  • Chemical Resistance: Compatible with ISO VG 32-68 hydraulic fluids

Certified Safety Performance

  • Intrinsic Safety: 250V max/100mA current limitation
  • Temperature Class: T4 (135°C surface) for gas environments
  • Ingress Protection: IP66 rated against dust/liquids
  • Compliance: CSA Class I Div 1, II 3G Ex ia IIC T4

Precision Specifications

  • Electrical: 9.87Ω ±0.50 DC resistance
  • Scale Factor: 7.87V/mm (±6.5%) over 0.25mm increments
  • Temperature Range: -62°F to +350°F (-52°C to +177°C)
  • Linearity: ±0.038mm (±1.5 mil) deviation

Durability Features

  • Material Construction: PPS tip with 304 SST housing (Rockwell B80)
  • Cable Strength: 330N (75 lbf) CableLoc™ pull-out resistance
  • Sealing System: Viton® O-rings rated for 100psi differential pressure
  • Warranty: 1-year manufacturer guarantee
