330162-02-85-85-80-80-94-01-02 Bently Nevada HP Feedthrough 3300

330162-02-85-85-80-80-94-01-02 Bently Nevada Dual Triaxial HP Feedthrough

• Brand: Bently Nevada – a global leader in machinery protection.
• Model Number: 330162-02-85-85-80-80-94-01-02 – Dual Triaxial HP Feedthrough.
• System Compatibility: Designed for 3300 System monitoring applications.
• Probe Support: Works with 3300 XL 8 mm, 3300 XL 11 mm, and 3300 5 mm probes.
• Pressure Rating: Seals 2.76 MPa (400 psi) inside the machine case.
• Cable Routing: Routes 2 cables through the case simultaneously.
• Connector Type: Corrosion-resistant gold-plated brass ClickLoc connectors.
• O-Ring Material: Fluorocarbon (option 94) – compatible with butane, fuel oil, natural gas, petroleum oil, and turbine oil.
• Origin: Made in the U.S.A. with premium materials.

Technical Specifications

• Manufacturer: Bently Nevada (Baker Hughes).
• Product Number: 330162-02-85-85-80-80-94-01-02.
• Product Type: 330162 Dual Triaxial HP Feedthrough for 3300 System.
• Armor Option (AA): 02 – with armor at low pressure end.
• Dimension 1 (BB): 85 – 8.5 metres.
• Dimension 2 (CC): 85 – 8.5 metres.
• Dimension 3 (DD): 80 – 8.0 metres (order in 0.1 m increments, minimum 0.5 m).
• Dimension 4 (EE): 80 – 8.0 metres (order in 0.1 m increments).
• O-Ring Material (FF): 94 – Fluorocarbon for hydrocarbon exposure.
• High Pressure End Connector (GG): 01 – female miniature coaxial connector.
• Low Pressure End Connector (HH): 02 – male miniature coaxial connector.
• Maximum Pressure: 2.76 MPa (400 psi) seal rating.
• Connector Plating: Gold-plated brass for corrosion resistance.
• Mating Torque: Finger-tight only – no tools required.

Frequently Asked Questions (FAQ)

• Q: Which probes work with the 330162-02-85-85-80-80-94-01-02 feedthrough?
  A: It supports 3300 XL 8 mm, 3300 XL 11 mm, and 3300 5 mm probes.
• Q: What pressure can this feedthrough seal?
  A: It seals up to 2.76 MPa (400 psi) inside the machine case.
• Q: What does the fluorocarbon O-ring (option 94) resist?
  A: It resists butane, fuel oil, natural gas, petroleum oil, and turbine oil.
• Q: Why are the connectors gold-plated?
  A: Gold plating provides corrosion resistance and reliable signal transfer.
• Q: Can I tighten the ClickLoc connectors with tools?
  A: No, finger-tight torque is sufficient – tools may damage the connectors.
• Q: How do I order custom lengths for this feedthrough?
  A: Specify lengths in 0.1-metre increments; minimum is 0.5 metre per section.
• Q: Is 330162-02-85-85-80-80-94-01-02 a genuine Bently Nevada product?
  A: Yes, this is an original OEM feedthrough made in the U.S.A.
