330173-00-18-10-02-05 Bently Nevada 5mm Probe M8x1

330173-00-18-10-02-05 – 5mm Proximity Probe by Bently Nevada

• Manufacturer: Bently Nevada (USA)
• Product No.: 330173-00-18-10-02-05 – 3300 5mm Probe, M8 x 1 thread, without armor
• Unthreaded Length: 00 = 0 mm
• Overall Case Length: 18 = 180 mm
• Total Cable Length: 10 = 1.0 metre (3.3 feet)
• Connector Type: 02 = Miniature coaxial ClickLoc connector, standard cable
• Agency Approval: 05 = Multiple approvals

Core Technical Specifications (System +18°C to +27°C, -24 Vdc supply, 10 kΩ load, AISI 4140 steel target, 1.27 mm gap)

• Power Supply: Requires -17.5 Vdc to -26 Vdc at 12 mA max consumption. Operating above -23.5 Vdc reduces linear range.
• Sensitivity (Supply Effect): Output voltage changes less than 2 mV per 1 V input change.
• Output Resistance: 50 Ω.
• Probe DC Resistance (1.0 m length): 7.59 ± 0.50 Ω from center to outer conductor.
• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 304 stainless steel (SST) per specification table, with reference to AISI 303/304 SST.
• Probe Cable: 75 Ω triaxial, FEP insulated. Available lengths: 0.5, 1, 2, 5, or 9 meters.
• Tensile Strength: 222 N (50 lbf) for probe case to lead, and for lead to extension cable connectors.
• Connector Material: Gold-plated brass or gold-plated beryllium copper.
• Recommended Probe Case Torque: 5.1 N·m (45 in·lb). Maximum torque: 7.3 N·m (65 in·lb).
• Connector-to-Connector Torque: Maximum 0.565 N·m (0.42 ft·lbf).
• Minimum Cable Bend Radius: 25.4 mm (1.0 in).
• Probe Temperature Range: -35°C to +177°C (-31°F to +351°F). Exposure below -34°C may damage the pressure seal.
• 60 Hz Magnetic Field Immunity (5 m system, up to 300 Gauss): Output voltage (mil pp/Gauss) at 10 mil gap: XL Proximitor Sensor 0.0119, Probe 0.0004, XL Ext. Cable 0.0004. At 90 mil gap: XL Proximitor Sensor 0.0133, Probe 0.0045, XL Ext. Cable 0.0045.
• Thread Engagement Limits (M8x1): Maximum length of thread engagement is 12 mm.

Frequently Asked Questions (FAQ)

• Q: Is the Bently Nevada 330173-00-18-10-02-05 a genuine new part?
  A: Yes, we supply only a brand-new original unit. No used or refurbished probes.
• Q: What target material do you use for the specifications?
  A: The electrical specs use an AISI 4140 steel target at 1.27 mm (50 mils) gap with -24 Vdc supply and 10 kΩ load.
• Q: Can I use this probe with an extension cable longer than 1 meter?
  A: The total system length must match the proximitor calibration. This probe has a fixed 1.0 m cable; you can add an extension cable if the system supports the total length.
• Q: What is the maximum case temperature for this probe?
  A: The probe withstands up to +177°C (+351°F) continuously, but avoid temperatures below -34°C to protect the pressure seal.
• Q: Do you have this probe in stock?
  A: Yes, we keep the 330173-00-18-10-02-05 in stock. We ship within 5 days via FedEx, UPS, or DHL.
• Q: What happens if I apply torque above the recommended value?
  A: Maximum case torque is 7.3 N·m (65 in·lb). Exceeding that may damage the probe case or threads.
• Q: Can I return the probe if it does not suit my application?
  A: You have 30 days to return the unused product in its original packaging.
• Q: Does the probe work with a -24 Vdc power supply only?
  A: The supply range is -17.5 Vdc to -26 Vdc. However, operation at more positive than -23.5 Vdc reduces linear range.
