330192-00-08-10-00 Bently Nevada 0.8 Inch 1m Cable Probe

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (17 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Bently Nevada 330192-00-08-10-00 1 Meter ETR Probe

  • Manufacturer & Model: Bently Nevada 330192-00-08-10-00 ETR probe for 3300 XL series.
  • Product Type: 8 mm Eddy Current Transducer with stainless steel armor.
  • Thread: 3/8-24 UNF. Case length: 0.8 inch. Cable: 1.0 meter.
  • Agency Approval: 00 = Not required. Made in U.S.A.

Key Specifications

  • RPROBE at 1.0 meter: 7.59 ± 0.50 Ohms.
  • Supply voltage: -17.5 to -26 Vdc, nominal -24 Vdc.
  • Sensitivity: 7.87 V/mm (200 mV/mil). Linear range: 2 mm.
  • Operating temperature: -52 to 177 degrees Celsius.
  • Humidity tolerance: 93% RH, less than 3% ASF change.

Physical Details

  • Case length: 0.8 inch (20.3 mm) - ultra short.
  • Cable length: 1.0 meter (3.3 feet).
  • Unthreaded section: Zero - threads start at shoulder.
  • Maximum wall thickness: 0.2 inches (5 mm).
  • Case material: AISI 303/304 SST. Tip: PPS.

System Requirements

  • Proximitor: 3300 XL 8mm (330180-90-00).
  • Extension cables: 3300 XL series only.
  • Target: AISI 4140 steel calibration.

Package Contents

  • Probe assembly with 1.0m armored cable.
  • 3/8-24 UNF lock nut and calibration certificate.
  • Installation instructions and connector cap.

Shipping

  • Weight: 0.3 kg (0.66 lb). Packaging: Cardboard tube.
  • Carriers: FedEx, UPS, DHL (2-5 business days).

Frequently Asked Questions

  • Q: What is the maximum wall thickness for this 0.8 inch probe?
    A: Safe maximum is 0.2 inches (5mm). Formula: 0.8in case - 0.5in minimum thread - 0.06in gap - 0.04in margin = 0.2in.
  • Q: Can I add extension cable to this 1.0 meter probe?
    A: Yes. Total system length (probe + extension) must match proximitor calibration. Example: 1.0m probe + 4.0m extension = 5.0m system.
  • Q: What does agency approval 00 mean?
    A: No hazardous location certifications. Use this probe only in non-hazardous (safe) areas. For explosive atmospheres, choose option 05 (CSA/ATEX/IECEx).
  • Q: Is this probe suitable for cold environments?
    A: The probe operates to -52°C, but the Viton pressure seal may fail below -34°C. Contact Bently for special sealing if sustained cold operation is needed.
  • Q: What proximitor works with this probe?
    A: The 3300 XL 8mm Proximitor (model 330180-90-00). Do not use with 5mm or other series proximitors.
