330702-00-26-10-02-05 Bently Nevada 11mm Proximity Probe

Bently Nevada 330702-00-26-10-02-05 – 3300 XL 11 mm Proximity Probe with Multiple Approvals

Key Technical Specifications

• Brand & Series: Bently Nevada – 3300 XL 11 mm Proximity Probes.
• Full Model Number: 330702-00-26-10-02-05.
• Probe Thread: 1/2-20 UNF with stainless steel armor.
• Unthreaded Length Option: 00 = 0.0 inches.
• Overall Case Length: 26 = 2.6 inches.
• Total Probe Length: 10 = 1.0 metre (3.3 feet).
• Connector Type: 02 = Miniature coaxial ClickLoc connector with standard cable.
• Agency Approval Option: 05 = Multiple Approvals (suitable for global hazardous area installations).
• Probe Tip Material: Polyphenylene sulfide (PPS) – robust and durable.
• Probe Case Material: AISI 304 stainless steel (SST).
• Cable Specification: 75 Ω triaxial FEP insulated cable, total length 1.0 meter.
• DC Resistance (RPROBE): 5.9 ± 0.5 ohms from center conductor to outer conductor.
• Operating & Storage Temperature: -51°C to +177°C (-60°F to +351°F).
• Low-Temperature Caution: Exposure below -34°C (-30°F) may damage the pressure seal.
• Pressure Seal Design: Viton* O-ring seals differential pressure between tip and case.
• Probe Case Torque (Max): 45.2 N•m (400 in•lb).
• Recommended Torque: 15.2 N•m (133 in•lb) for 1/2-20 thread.
• Maximum Thread Engagement Length: 0.750 inch (19.05 mm).
• Connector Torque: Finger tight recommended; max 0.565 N•m (5 in•lb).
• Minimum Bend Radius (cable): 25.4 mm (1.0 inch) with or without armor.
• Shipping Weight: 0.17 kg – lightweight and easy to handle.

Frequently Asked Questions (FAQ)

• Q: Is the 330702-00-26-10-02-05 a genuine Bently Nevada probe?
  A: Yes, we provide 100% brand new, original Bently Nevada stock. No clones or used parts.
• Q: What does the “05” agency approval option mean?
  A: Option 05 means Multiple Approvals for global hazardous areas. This includes ATEX, IECEx, and other regional certifications.
• Q: What is the total cable length of this specific model?
  A: The “10” total length option equals 1.0 meter (3.3 feet). Other lengths like 5m or 9m require different order codes.
• Q: Can this probe operate at +177°C continuously?
  A: Yes, the probe works from -51°C to +177°C. Avoid prolonged exposure below -34°C to protect the Viton pressure seal.
• Q: How long does delivery take after ordering?
  A: We ship within 5 business days via FedEx, UPS, or DHL. Transit times typically range from 3 to 7 business days.
• Q: What torque should I apply to the probe case?
  A: For the 1/2-20 UNF thread, apply recommended 15.2 N•m (133 in•lb). Maximum rated torque is 45.2 N•m.
• Q: Is the probe pressure tested at the factory?
  A: No, Bently Nevada does not perform pressure tests before shipping. The Viton seal handles differential pressure. Request a custom pressure test from our design department.
• Q: What is the minimum bend radius for the probe cable?
  A: Do not bend the cable tighter than 25.4 mm (1.0 inch) to avoid damaging the triaxial FEP insulation.
• Q: Can I return the probe if it does not fit my machine?
  A: Yes, we accept returns within 30 days of delivery. The probe must be unused and in original packaging.
• Q: What DC resistance should I measure for this 1.0m probe?
  A: Measure between center conductor and outer conductor. Normal range is 5.9 ± 0.5 ohms for the 1.0 meter length.
