330702-00-26-50-01-05 | Bently Nevada 3300 XL 11mm Probe

Bently Nevada 330702-00-26-50-01-05 3300 XL 11 mm Proximity Probe

Product Overview

• Manufacturer: Bently Nevada (Made in U.S.A.)
• Series: 3300 XL
• Model Number: 330702-00-26-50-01-05
• Category: 11 mm Proximity Probe with Armor

Technical Specifications

• Probe Tip Material: Polyphenylene sulfide (PPS) for excellent wear and chemical resistance.
• Probe Case Material: AISI 304 stainless steel (SST) for long-term durability in industrial environments.
• Probe Cable: 75 Ω triaxial, fluoroethylene propylene (FEP) insulated cable.
• Mounting Thread: 1/2-20 UNF, with a maximum thread engagement of 0.750 inches.
• Case Length (Option 26): 2.6 inches (66.0 mm).
• Total Length (Option 50): 5.0 meters (16.4 feet).
• Connector (Option 01): Miniature coaxial ClickLoc connector with a connector protector.
• Agency Approval (Option 05): Multiple Approvals for global compliance.

Electrical & Environmental Ratings

• DC Resistance (RPROBE): 7.2 ± 0.8 ohms (Center to Outer Conductor).
• Operating & Storage Temperature: -51°C to +177°C (-60°F to +351°F).
• Temperature Classification: This probe meets T1 to T5 temperature ratings for hazardous area use.
• Pressure Seal: The probe uses a Viton O-ring for differential pressure sealing.
• Minimum Bend Radius: 25.4 mm (1.0 inch) for the probe cable.

Installation & Torque Guidelines

• Recommended Mounting Torque: 15.2 N•m (133 in•lb).
• Maximum Mounting Torque: 45.2 N•m (400 in•lb).
• Connector Torque: Finger tight, with a maximum of 0.565 N•m (5 in•lb).

Package Contents

• 1 x 330702-00-26-50-01-05 3300 XL 11 mm Probe with armor.
• 1 x Miniature coaxial ClickLoc connector protector.
• Installation manual.

Shipping & Logistics

• Shipping Weight: 0.17 Kg.
• Shipping Methods: We ship via FedEx, UPS, and DHL.
• Delivery Time: We process and ship all orders within 5 business days.
• Returns: We support returns within 30 days of delivery.

Frequently Asked Questions (FAQ)

• Q: What is the total cable length of the 330702-00-26-50-01-05?
  A: This probe has a total length of 5.0 meters (16.4 feet).
• Q: Is this probe compatible with any Proximitor?
  A: No, this five meter probe is specifically designed for use with the five meter Proximitor Sensor only.
• Q: Does this model have agency approvals?
  A: Yes, the "05" suffix indicates it has Multiple Approvals.
• Q: What is the thread size for this probe?
  A: It uses a 1/2-20 UNF thread with a maximum engagement of 0.750 inches.
• Q: What is the recommended mounting torque?
  A: The recommended torque is 15.2 N•m (133 in•lb). The maximum is 45.2 N•m (400 in•lb).
• Q: Is the probe cable armored?
  A: Yes, this model includes stainless steel armor for cable protection.
• Q: Is the 330702-00-26-50-01-05 a new and original product?
  A: Yes, we guarantee it is a brand new, original product from Bently Nevada.
• Q: Is this product in stock?
  A: Yes, we have this model in stock and ready to ship.
