330702-00-26-90-12-05 New Bently Nevada 11 mm Probe

Bently Nevada 330702-00-26-90-12-05: 3300 XL 11 mm Proximity Probe with 9.0 Meter Cable

• Brand and Model: Bently Nevada 330702-00-26-90-12-05 comes from the 3300 XL 11 mm series. This probe delivers high accuracy for critical machine protection.
• Thread and Armor: The probe uses 1/2-20 UNF thread with full armor. This design secures installation and protects the cable from mechanical stress.
• Unthreaded Length: Option 00 sets this value to 0.0 inches. This simplifies positioning near the target surface.
• Overall Case Length: Option 26 gives you 2.6 inches. This compact case fits tight machine spaces easily.
• Total Probe Length: Option 90 provides 9.0 meters (29.5 feet). This long length suits remote installations or large machinery.
• Connector and Cable: Option 12 includes a miniature coaxial ClickLoc connector with FluidLoc cable. This connector prevents fluid ingress and secures the connection.
• Agency Approval: Option 05 grants Multiple Approvals. You can use this probe in global industrial sites confidently.
• Probe Tip Material: The tip uses Polyphenylene sulfide (PPS). This material resists chemicals and wear over long periods.
• Probe Case Material: The case is AISI 304 stainless steel (SST). It prevents corrosion in wet or oily environments.
• Cable Specification: The cable is 75 Ω triaxial with FEP insulation. It resists high temperatures and maintains signal integrity.
• Available Probe Lengths: You can order this probe series in 1, 5 or 9 meters. Choose the best length for your machine layout.
• DC Resistance for 9.0 Meter Length: The resistance from center to outer conductor measures 8.5 ± 1.1 ohms. This low resistance ensures reliable signal transmission.
• Operating Temperature: The probe works from -51°C to +177°C (-60°F to +351°F). It withstands extreme heat or cold in continuous operation.
• Storage Temperature: Same range as operating temperature: -51°C to +177°C. Store the probe without any performance loss.
• Pressure Seal Design: The probe uses a Viton O-ring for differential pressure sealing. Bently Nevada does not pressure-test each unit before shipping.
• Probe Case Thread (Imperial): Thread size is 1/2-20. Maximum thread engagement length reaches 0.750 inches.
• Maximum Torque for Case: Do not exceed 45.2 N•m (400 in•lb). Overtightening may damage the probe or its mounting.
• Recommended Torque: Apply 15.2 N•m (133 in•lb). This torque provides a secure fit without unwanted stress.
• Connector Torque: Finger tight is the recommended torque. Maximum torque equals 0.565 N•m (5 in•lb). Tighten gently to avoid thread damage.
• Minimum Bend Radius: For cable with or without SST armor, bend radius is 25.4 mm (1.0 inch). Keep bends wider to protect internal conductors.
• Alternative Metric Threads: Probe case thread also comes as M16x1.5 with 24 mm engagement. Another option is M14x1.5 with 21 mm engagement.
• Temperature Warning: Exposing the probe below -34°C (30°F) may cause premature seal failure. Please respect this operating limit.
• Shipping Weight: Each probe weighs only 0.17 kg. This lightweight design reduces shipping costs and handling effort.

Frequently Asked Questions (FAQ)

• Do you have this model in stock?
  Yes, we keep the 330702-00-26-90-12-05 in stock. You can place your order immediately for quick dispatch.
• What is your shipping time?
  We ship within 5 days after we confirm your order. Most orders leave our warehouse even earlier.
• Which carriers do you use?
  We ship via FedEx, UPS, and DHL. You can choose your preferred courier at checkout.
• Can I return this probe?
  Yes, we support 30-day returns from the delivery date. The probe must remain unused and in original condition.
• What is the DC resistance for the 9.0 meter probe?
  For the 9.0 meter length, DC resistance measures 8.5 ± 1.1 ohms between center and outer conductor.
• What happens if I expose the probe below -34°C?
  Exposure below -34°C may permanently damage the Viton pressure seal. This damage is not covered under our return policy.
• Does this probe work with 3300 XL extension cables?
  Yes, the 3300 XL 11 mm series works with standard Bently Nevada extension cables and proximitors.
• What approvals does option 05 include?
  Option 05 means Multiple Approvals for global industrial use. It complies with major international safety standards.
• Is the probe tip replaceable?
  No, the PPS tip is permanently attached to the probe. You need to replace the whole 330702-00-26-90-12-05 if the tip wears out.
• What is the minimum bend radius for the armored cable?
  The minimum bend radius is 25.4 mm (1.0 inch) with or without stainless steel armor.
• Can I use this probe in a high-vibration environment?
  Yes, the 3300 XL series handles high vibration levels. The armored cable and secure thread provide excellent reliability.
