Bently Nevada 3300 XL 11 mm Probe – 330702-00-30-90-12-05

• Product Type: 3300 XL 11 mm Probe, 1/2-20 UNF thread, with armor.
• Manufacturer: Bently Nevada (Made in U.S.A.).
• Unthreaded Length Option: 0 inches (00 option).
• Overall Case Length: 3.0 inches (30 option).
• Total Length: 9.0 meters / 29.5 feet (90 option).
• Connector & Cable: Miniature coaxial ClickLoc connector with FluidLoc cable (12 option).
• Agency Approval: Multiple Approvals (05 option).

Key Technical Specifications

• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 304 stainless steel (SST).
• Probe Cable: 75 Ω triaxial, FEP insulated, available in 1, 5, or 9 meters.
• DC Resistance (RPROBE): 8.5 ± 1.1 ohms (center to outer conductor) for 9.0m length.
• Operating & Storage Temperature: -51°C to +177°C (-60°F to +351°F).
• Probe Pressure Seal: Viton O-ring design (not pressure tested prior to shipment).
• Shipping Weight: 0.17 Kg.

Mechanical & Installation Guidelines

• Case Thread: 1/2-20 UNF (max thread engagement 0.750 in).
• Maximum Rated Torque: 45.2 N•m (400 in•lb).
• Recommended Torque: 15.2 N•m (133 in•lb) for the probe case.
• Connector Torque: Finger tight recommended; max 0.565 N•m (5 in•lb).
• Minimum Bend Radius: 25.4 mm (1.0 in) with or without SST armor.
• Other Thread Options: M16x1.5 (24 mm engagement) and M14x1.5 (21 mm engagement).
• Temperature Caution: Exposing the probe below -34°C (-30°F) may damage the pressure seal.

Environmental & Durability Features

• Wide temperature range: -52°C to +177°C (-62°F to +351°F) for storage and operation.
• Stainless steel case provides excellent corrosion resistance.
• PPS tip material offers high chemical and thermal stability.
• Armored cable option ensures mechanical protection in demanding installations.
• FluidLoc cable design prevents fluid ingress and enhances reliability.

Package Contents

• 1 x 3300 XL 11 mm Probe (330702-00-30-90-12-05) with armor.
• Pre-installed miniature coaxial ClickLoc connector with protector.
• FluidLoc triaxial cable (9.0 meters total length).
• Viton O-ring pressure seal (factory installed).

Shipping & Logistics

• Shipping Weight: 0.17 Kg per unit.
• Carrier Options: FedEx, UPS, DHL (available at checkout).
• Delivery Time: Ships within 5 business days from our stock.
• Return Policy: 30-day return window for unused items in original packaging.

Frequently Asked Questions (FAQ)

• Q: Is this probe new and original?
  A: Yes, we supply 100% new, factory-sealed Bently Nevada 330702-00-30-90-12-05 units.
• Q: What is the probe's total cable length?
  A: This version includes a 9.0 meter (29.5 feet) cable with armor.
• Q: Can I use this probe in high-pressure applications?
  A: The Viton O-ring seals differential pressure, but we do not pressure-test prior to shipment. Contact our custom design department for pressure-test requirements.
• Q: What is the minimum bend radius for the cable?
  A: The minimum bend radius is 25.4 mm (1.0 in) whether or not you use the stainless steel armor.
• Q: Do you have this item in stock?
  A: Yes, we maintain inventory and ship within 5 days after order confirmation.
• Q: Which thread option does this probe have?
  A: This model uses a 1/2-20 UNF thread with 0.750 in maximum engagement.
• Q: What is the DC resistance value for the 9m probe?
  A: The resistance from center to outer conductor is 8.5 ± 1.1 ohms.
• Q: What is FluidLoc cable?
  A: FluidLoc cable features a special jacket that prevents fluid wicking along the cable, improving reliability in wet environments.
