330703-000-060-10-11-00 Bently Nevada | 3300 XL 11 mm Probe

Part Number: 330703-000-060-10-11-00
Model: 3300 XL 11 mm Proximity Probes, Metric
Brand: Bently Nevada
Condition: New & Original in Factory Packing
Factory Warranty: 12 Months

Detailed Configuration:
Model: 330703 - 3300 XL 11 mm Probe, M14 x 1.5 thread, without armor
Unthreaded Length: 000 – 00 mm
Overall Case Length: 060 – 60.0 mm
Total Length: 10 – 1.0 metre (3.3 feet)
Connector and Cable: 11 – Miniature coaxial ClickLoc connector with protector, FluidLoc cable
Agency Approval: 00 – Not required

Performance Characteristics:
• DC Resistance: 5.9 ± 0.5 ohms at 1.0 meter length
• Cable Specification: 75 Ω triaxial, FEP insulated
• Maximum Thread Engagement: 21 mm
• Max Case Torque: 63.3 N•m (560 in•lb)
• Recommended Torque: 21.1 N•m (187 in•lb)

Magnetic Field Influence (60 Hz, up to 300 Gauss):
• At 0.5 mm gap: 0.001 mil pp/gauss
• At 2.5 mm gap: 0.009 mil pp/gauss
• At 4.6 mm gap: 0.027 mil pp/gauss

Construction Materials:
• Probe Tip: Polyphenylene sulfide (PPS)
• Probe Case: AISI 304 Stainless Steel
• Cable Jacket: Fluoroethylene propylene (FEP)

Additional Measured Parameters:
• Heat Resistance: Maintains structural integrity up to 177°C continuously
• Installation Flexibility: Available total lengths: 1, 5, or 9 meters
• Pressure Seal Integrity: Maintained in wide thermal ranges above -34°C
