330704-000-060-90-02-CN Bently Nevada - 3300 XL 11mm Probe

330704-000-060-90-02-CN Bently Nevada 3300 XL 11 mm Proximity Probe – 9 Meter System with Country Specific Approval

• Brand & Complete Model: Bently Nevada 330704-000-060-90-02-CN (3300 XL 11 mm Probe, M14 x 1.5 thread, armored).
• Unthreaded Length Option (000): 00 mm for straightforward mounting.
• Overall Case Length Option (060): 60.0 mm for extended installation depth.
• Total Length Option (90): 9.0 meters (29.5 feet) for remote monitoring applications.
• Connector & Cable Type Option (02): Miniature coaxial ClickLoc connector with standard cable.
• Agency Approval Option (CN): Country specific approval for regional compliance.

Technical Specifications – Core Parameters

• Probe DC Resistance (RPROBE): 8.5 ± 1.1 ohms for 9.0 metre probe length (center to outer conductor).
• 60 Hz Magnetic Field Rejection (up to 300 Gauss, 5 m system):
  - 0.5 mm (20 mil) gap: output 0.001 mV pp/gauss.
  - 2.5 mm (100 mil) gap: output 0.009 mV pp/gauss.
  - 4.6 mm (180 mil) gap: output 0.027 mV pp/gauss.
• Probe Tip Material: Polyphenylene sulfide (PPS) for outstanding chemical resistance.
• Probe Case Material: AISI 304 stainless steel (SST) providing rugged durability.
• Probe Cable Specification: 75 Ω triaxial cable with FEP insulation. Available total lengths: 1, 5, or 9 metres.
• Maximum Recommended Torque: 21.1 N•m (187 in•lb). Maximum rated torque: 63.3 N•m (560 in•lb).
• Thread Size: M14 x 1.5 with maximum thread engagement of 21 mm.
• Operating & Storage Temperature: -52°C to +177°C (-62°F to +351°F). Caution: Do not expose the probe below -34°C (-30°F) – it may damage the pressure seal prematurely.

Frequently Asked Questions (FAQ)

• Q: Is this 330704-000-060-90-02-CN probe brand new?
  A: Yes, it is 100% new and original in factory packing.
• Q: Do you have this model in stock?
  A: Yes, we keep the 330704-000-060-90-02-CN in stock for immediate orders.
• Q: What is the return policy?
  A: We support returns within 30 days from the delivery date.
• Q: How soon will you ship the probe?
  A: We ship within 5 days after you place the order.
• Q: What does the CN approval option mean?
  A: CN indicates country specific approval for regional regulatory compliance in certain markets.
• Q: Does the 9 metre cable work with any Proximitor Sensor?
  A: Yes, 9 metre probes work with compatible 3300 XL proximity systems. Please verify your Proximitor Sensor specifications.
• Q: Does the probe work at -50°C continuously?
  A: Yes, the probe operates from -52°C to +177°C, but avoid temperatures below -34°C to protect the pressure seal.
• Q: Can I use this probe in a high magnetic field area?
  A: Yes, the 3300 XL series shows very low output (0.001 to 0.027 mV pp/gauss) under 300 Gauss at common gaps.
• Q: Which carriers do you use for international shipping?
  A: We use FedEx, UPS, and DHL for fast and reliable delivery.
