3300 XL 11 mm Proximity Probe – Model 330704

Key Technical Specifications

• Brand & Series: Bently Nevada – 3300 XL 11 mm Proximity Probes.
• Full Model: 330704-000-100-10-01-CN (with country-specific agency approval).
• Unthreaded Length: 00 mm (standard option).
• Overall Case Length: 100 mm.
• Total Probe Length: 1.0 metre (3.3 feet).
• Connector Type: Miniature coaxial ClickLoc connector with protector, standard cable.
• Probe DC Resistance (RPROBE): 5.9 ± 0.5 ohms for a 1.0 m length (center to outer conductor).
• 60 Hz Magnetic Field Immunity (5 m system):
  • At 0.5 mm gap (20 mil): 0.001 mV pp/gauss.
  • At 2.5 mm gap (100 mil): 0.009 mV pp/gauss.
  • At 4.6 mm gap (180 mil): 0.027 mV pp/gauss.
• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 304 stainless steel (SST).
• Cable Specification: 75 Ω triaxial with FEP insulation. Total probe cable lengths available: 1, 5, or 9 meters.
• Operating & Storage Temperature: -52°C to +177°C (-62°F to +351°F). Exposing the probe below -34°C (30°F) may damage the pressure seal.
• Maximum Case Torque: 63.3 N•m (560 in•lb). Recommended torque: 21.1 N•m (187 in•lb).
• Thread Engagement Maximum Length: 21 mm for M14x1.5 thread.

Frequently Asked Questions (FAQ)

• Q: Is this probe brand new and original?
  A: Yes, we supply only new & original Bently Nevada probes in factory packing.
• Q: What is the exact thread size for the 330704 probe?
  A: The 330704 model uses a M14 x 1.5 metric thread.
• Q: Can I use this probe in high-temperature environments?
  A: Yes, it operates from -52°C to +177°C. Refer to the temperature schedule for specific T-class ratings.
• Q: How does the probe resist magnetic interference?
  A: At 2.5 mm gap, the 60 Hz field effect is only 0.009 mV pp/gauss, ensuring stable readings near motors or generators.
• Q: Do you have this item in stock?
  A: Yes, we maintain local stock. We can ship your order within 5 days.
• Q: Which couriers do you use for international delivery?
  A: We ship via FedEx, UPS, or DHL for fast and reliable service.
• Q: What is the return policy for this proximity probe?
  A: You may return unopened items within 30 days for a full refund.
• Q: Is the ClickLoc connector included?
  A: Yes, the 330704 probe includes a miniature coaxial ClickLoc connector with a protective cap.
