330704-010-100-10-01-05 Bently Nevada 3300 XL 11 mm Proximity Probe – Precision Metric Sensing

• Brand & model core: Bently Nevada designs the 330704-010-100-10-01-05 for harsh turbomachinery environments. This 3300 XL 11 mm probe offers superior linear range and temperature stability.
• Unthreaded length option: 010 = 10 mm. The overall case length option 100 equals 100 mm. These dimensions fit standard metric mounting holes precisely.
• Total length & connector: Option 10 gives a 1.0 metre (3.3 feet) cable. Option 01 provides a miniature coaxial ClickLoc connector with a connector protector and standard cable.
• Agency approval: Option 05 = multiple approvals. This simplifies global compliance for your installations.
• Probe DC resistance: For a 1.0 metre probe length, the resistance from the center conductor to the outer conductor (RPROBE) measures 5.9 ± 0.5 ohms. This ensures accurate signal transmission.

Key Technical Specifications – Performance You Can Rely On

• Measurement & frequency response: The 330704-010-100-10-01-05 operates as a 11 mm proximity probe system. It detects shaft vibration and position with high repeatability.
• Effects of 60 Hz magnetic fields (up to 300 Gauss, 5 meter system): At 0.5 mm gap (20 mil), output voltage equals 0.001 mil pp/gauss. At 2.5 mm gap (100 mil), output equals 0.009 mil pp/gauss. At 4.6 mm gap (180 mil), output equals 0.027 mil pp/gauss. This shows excellent magnetic field immunity.
• Probe tip material: Polyphenylene sulfide (PPS). This non-conductive tip resists chemicals and wear.
• Probe case material: AISI 304 stainless steel (SST). It provides corrosion resistance and mechanical strength.
• Cable specification: 75 Ω triaxial cable with fluoroethylene propylene (FEP) insulation. Total probe lengths available: 1, 5 or 9 meters. The 330704-010-100-10-01-05 with 1.0m cable suits short-range monitoring.
• Probe case torque: Maximum rated torque = 63.3 N•m (560 in•lb). Recommended torque = 21.1 N•m (187 in•lb). This prevents overtightening damage.
• Thread details: M14x1.5 thread. Maximum length of thread engagement = 21 mm. Ensure proper depth for secure mounting.

Frequently Asked Questions (FAQ)

• Is the 330704-010-100-10-01-05 probe brand new and original? Yes, we supply only new & original Bently Nevada items in factory packing. No used or counterfeit parts.
• Do you have stock for the 330704-010-100-10-01-05 model? Yes, we keep this configuration in stock. It is ready for immediate order.
• How soon will you ship after we place an order? We ship within 5 days. Most orders leave our warehouse in 2-3 business days.
• What logistics carriers do you use? We use DHL, FedEx, and UPS. You can select your preferred courier at checkout.
• Does the probe work with a 5 mm or 8 mm proximity system? No. The 3300 XL 11 mm probe is for 11 mm systems. It is not interchangeable with 5 mm or 8 mm probes.
• What is the maximum thread engagement length? Maximum length of thread engagement = 21 mm. Longer engagement may damage the probe case.
• Can I return the probe for a refund? Yes, we support 30-day returns. The item must be unused and in original packing.
• Is the probe temperature rated for outdoor -50°C applications? Yes, operating range goes down to -52°C. However keep above -34°C to avoid pressure seal failure.
• Does the probe include the extension cable or driver? No, the 330704-010-100-10-01-05 is only the proximity probe with 1.0m integrated cable. You need a compatible Bently Nevada proximitor and extension cable separately.
