330707-00-25-50-02-00 Bently Nevada 3300 XL Armored Probe

Bently Nevada 330707-00-25-50-02-00 3300 XL 11 mm Armored Proximity Probe

Key Technical Specifications

• Manufacturer: Bently Nevada (Made in U.S.A).
• Model: 330707-00-25-50-02-00.
• Type: 3300 XL 11 mm Proximity Probe with armor.
• Unthreaded Length: 0 inches (option 00).
• Overall Case Length: 2.5 inches (option 25).
• Total Probe Length: 5.0 meters (16.4 feet, option 50).
• Connector Type: Miniature coaxial ClickLoc connector, standard cable (option 02).
• Agency Approval: Not required (option 00).
• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 304 stainless steel (SST).
• Armor: Stainless steel armor over the cable.
• Cable Specification: 75 Ω triaxial, FEP insulated cable.
• DC Resistance (Center to Outer): 7.2 ± 0.8 ohms (for 5.0m length).
• Operating Temperature: -51°C to +177°C (-60°F to +351°F).
• Storage Temperature: -51°C to +177°C.
• Pressure Seal: Viton O-ring design.
• Shipping Weight: 0.17 Kg.

Mechanical & Installation Data

• Case Thread: 1/2-20 UNF.
• Max Thread Engagement: 0.750 inches.
• Rated Case Torque: 45.2 N•m (400 in•lb).
• Recommended Case Torque: 15.2 N•m (133 in•lb).
• Connector Torque: Finger tight (max 0.565 N•m / 5 in•lb).
• Minimum Bend Radius: 25.4 mm (1.0 inch) with or without armor.
• Probe Case Thread (M16x1.5): Max engagement 24 mm.
• Probe Case Thread (M14x1.5): Max engagement 21 mm.
• Compatibility Note: Use this 5.0m probe only with the 5.0m Proximitor Sensor.

Temperature Classifications (Probe Only)

• EPL Ga/Gc T1: -55°C to +232°C.
• EPL Ga/Gc T2: -55°C to +177°C.
• EPL Ga/Gc T3: -55°C to +120°C.
• EPL Ga/Gc T4: -55°C to +80°C.
• EPL Ga/Gc T5: -55°C to +40°C.
• EPL Dc T280°C: -55°C to +232°C.
• EPL Dc T225°C: -55°C to +177°C.
• EPL Dc T170°C: -55°C to +120°C.
• EPL Dc T130°C: -55°C to +80°C.
• EPL Dc T105°C: -55°C to +100°C.
• EPL Dc T90°C: -55°C to +40°C.

Package Contents & Logistics

• One Bently Nevada 330707-00-25-50-02-00 armored proximity probe.
• Connector protector and standard cable assembly.
• Installation guide and safety instructions (digital).
• We ship via FedEx, UPS, or DHL.
• We process orders within 5 business days.
• This is a brand new, original unit in stock.

Frequently Asked Questions (FAQ)

• Q: Is this a genuine Bently Nevada probe?
  A: Yes, it is a brand new, original 330707-00-25-50-02-00 from Bently Nevada.
• Q: Does this probe include cable armor?
  A: Yes, this model features stainless steel armor for enhanced cable protection.
• Q: What is the total cable length?
  A: The total length is 5.0 meters (16.4 feet) with a 75 Ω triaxial FEP cable.
• Q: What thread size does the case use?
  A: It uses a 1/2-20 UNF thread with a 0.750-inch maximum engagement.
• Q: Can I use this probe with any Proximitor Sensor?
  A: No, this 5.0-meter probe works exclusively with the 5.0-meter Proximitor Sensor.
• Q: What is the recommended installation torque?
  A: Bently Nevada recommends 15.2 N•m (133 in•lb) for the probe case.
• Q: Do you have this probe in stock?
  A: Yes, we have stock and ship within 5 days of order confirmation.
• Q: What shipping methods do you offer?
  A: We use DHL, FedEx, or UPS for reliable delivery.
• Q: What is your return policy?
  A: We accept returns within 30 days of delivery.
