330709-000-060-50-01-05 11 mm Proximity Probe Bently Nevada

Bently Nevada 330709-000-060-50-01-05 – 3300 XL 11 mm Proximity Probe

• Brand & Model: Bently Nevada 330709-000-060-50-01-05 (3300 XL 11 mm Proximity Probe).
• Unthreaded length option: 000 = 0 mm – no extra unthreaded section.
• Overall case length: 060 = 60 mm compact stainless steel case.
• Total probe length: 50 = 5.0 meters (16.4 feet). This probe only works with the five meter Proximitor Sensor.
• Connector type: 01 = Miniature coaxial ClickLoc connector with connector protector and standard cable.
• Agency approval option: 05 = Multiple Approvals for global industrial compliance.

Core Technical Specifications

• Probe DC resistance (RPROBE): 7.2 ± 0.8 ohms for 5.0 m length (center to outer conductor).
• Target flat surface minimum diameter: 30.5 mm (1.2 inches) to avoid measurement errors.
• Recommended minimum shaft diameter: 152 mm (6.0 inches) for cross-talk limitation.
• Probe tip material: Polyphenylene sulfide (PPS) offering excellent chemical resistance.
• Probe case material: AISI 304 stainless steel (SST) for durability in harsh environments.
• Cable specification: 75 Ω triaxial, FEP insulated cable. Total lengths available: 1, 5 or 9 meters.
• Connector torque (finger tight): recommended finger tight; maximum 0.565 N•m (5 in•lb).
• Minimum bend radius (with or without SST armor): 25.4 mm (1.0 inch) for safe cable routing.
• Probe case thread: M16x1.5 with maximum thread engagement 24 mm.
• Temperature range (operating & storage): -52°C to +177°C (-62°F to +351°F). Exposing below -34°C (30°F) may damage the pressure seal.
• Probe case torque (M16x1.5): maximum rated 63.3 N•m (560 in•lb); recommended 21.1 N•m (187 in•lb).

Frequently Asked Questions (FAQ)

• Q: Is this Bently Nevada 330709-000-060-50-01-05 probe brand new and original?
  A: Yes, we supply only brand new original Bently Nevada probes. No refurbished or counterfeit units.
• Q: Do you have the 330709-000-060-50-01-05 in stock?
  A: Yes, we keep this 330709-000-060-50-01-05 in stock ready to ship today.
• Q: What is the lead time for shipping this 5m proximity probe?
  A: We dispatch orders within 5 days. Then carriers like DHL, FedEx, or UPS deliver quickly.
• Q: What does the “05” approval option mean for this probe?
  A: The 330709-000-060-50-01-05 includes multiple approvals (ATEX, IECEx, etc.) for hazardous areas. It meets global safety standards.
• Q: Can I use this 5m probe with a standard extension cable?
  A: No, the 330709-000-060-50-01-05 five meter probe works only with the five meter Proximitor Sensor. Do not mix with other lengths.
• Q: What is the maximum temperature limit for this probe?
  A: The probe operates from -52°C to +177°C (-62°F to +351°F). Respect specific T-class ratings for hazardous areas.
• Q: What torque should I apply to the M16x1.5 probe case?
  A: Apply 21.1 N•m (187 in•lb) recommended torque. Do not exceed 63.3 N•m (560 in•lb) to avoid damage.
• Q: Does the probe include armor?
  A: This model has without armor as indicated by the 330709 base number. If you need armor, choose a different option.
• Q: Can I return the product within 30 days?
  A: Absolutely. We support 30 days return from delivery for unused items in original packaging.
