330709-000-060-50-11-00 Bently Nevada 3300 XL Probe 5m

Bently Nevada 330709-000-060-50-11-00 – 3300 XL 11 mm Proximity Probe

• Brand & Model: Bently Nevada 330709-000-060-50-11-00 – 3300 XL 11 mm Proximity Probe.
• Unthreaded Length Option: 000 = 0 mm – no extra unthreaded section.
• Overall Case Length Option: 060 = 60 mm – standard compact case.
• Total Length Option: 50 = 5.0 meters (16.4 feet). This five-meter probe works only with the five-meter Proximitor Sensor.
• Connector & Cable Type: 11 = Miniature coaxial ClickLoc connector with connector protector and FluidLoc cable.
• Agency Approval: 00 = Not required for standard industrial use.

Key Technical Specifications

• Probe DC Resistance: For 5.0m length, 7.2 ± 0.8 ohms from center to outer conductor.
• Cross-talk Limitation: Requires flat target diameter minimum 30.5 mm (1.2 in). Shaft diameter minimum 152 mm (6.0 in).
• Probe Tip Material: Polyphenylene sulfide (PPS) – durable and chemical resistant.
• Probe Case Material: AISI 304 stainless steel (SST) for harsh environments.
• Probe Cable Specification: 75 Ω triaxial, fluoroethylene propylene (FEP) insulated cable. Total lengths available: 1, 5 or 9 meters.
• Connector Torque: Finger tight recommended. Maximum torque 0.565 N•m (5 in•lb).
• Minimum Bend Radius: 25.4 mm (1.0 in) with or without SST armor.
• Probe Case Thread: M16x1.5 with maximum thread engagement of 24 mm.

Temperature Range & Thermal Classification

• Operating & Storage Temperature: -52°C to +177°C (-62°F to +351°F). Exposing the probe below -34°C (30°F) may cause premature pressure seal failure.
• For EPL Ga and Gc: T1 (-55°C to +232°C), T2 (-55°C to +177°C), T3 (-55°C to +120°C), T4 (-55°C to +80°C), T5 (-55°C to +40°C).
• For EPL Dc: T280°C @ Ta (-55°C to +232°C), T225°C @ Ta (-55°C to +177°C), T170°C @ Ta (-55°C to +120°C), T130°C @ Ta (-55°C to +80°C), T90°C @ Ta (-55°C to +40°C).

Mechanical Torque & Installation Guidelines

• Probe Case Torque for M16x1.5: Maximum rated 63.3 N•m (560 in•lb). Recommended torque 21.1 N•m (187 in•lb).
• Maximum Thread Engagement Length: 24 mm for M16x1.5 threads.
• Installation Tip: Always hand-tighten the ClickLoc connector first. Use a torque wrench only up to 0.565 N•m.
• Avoid tight bending: Keep bend radius larger than 25.4 mm to prevent cable damage.
• Compatible Proximitor: Use only with the five-meter Proximitor Sensor (model 3300 XL).

Frequently Asked Questions (FAQ)

• Is the 330709-000-060-50-11-00 brand new and original?
  Yes, we supply only brand new, original Bently Nevada probes. No refurbished or counterfeit items.
• Do you have this 5m probe in stock?
  Absolutely. We keep the 330709-000-060-50-11-00 in our warehouse for immediate shipment.
• How long does delivery take?
  We dispatch within 5 days after order confirmation. Then FedEx, UPS or DHL delivers typically in 3-7 business days.
• Can I use this probe with an extension cable?
  This 5-meter probe is designed only for direct connection to a five-meter Proximitor Sensor. Do not add extension cables.
• What is the maximum temperature for this probe?
  The probe operates continuously from -52°C to +177°C. Refer to T-class tables for hazardous area use.
• What torque should I apply to the M16x1.5 threads?
  We recommend 21.1 N•m (187 in•lb). Never exceed 63.3 N•m to avoid thread damage.
• Do I need special tools for the ClickLoc connector?
  No, finger tight is sufficient. Maximum torque 0.565 N•m ensures reliable connection without overstress.
• What is the minimum target diameter?
  For flat surfaces, use a target diameter of at least 30.5 mm (1.2 inch). For shafts, minimum diameter is 152 mm (6.0 inch).
• Can I return the probe if it doesn't fit my application?
  Yes, you have 30 days to return this product. It must be in original condition.
