Bently Nevada 330709-000-060-50-12-05: 3300 XL 11 mm Proximity Probe

Key Technical Specifications

• Brand: Bently Nevada (Made in U.S.A).
• Model: 330709-000-060-50-12-05 (3300 XL series).
• Probe Type: 3300 XL 11 mm Proximity Probe.
• Thread Size: M16 x 1.5 probe case thread.
• Unthreaded Length: 0 mm (Option 000).
• Overall Case Length: 60 mm (Option 060).
• Total Probe Length: 5.0 meters (16.4 feet) – Option 50.
• Cable & Connector: Miniature coaxial ClickLoc connector with FluidLoc cable (Option 12).
• Agency Approval: Multiple Approvals (Option 05).
• Probe DC Resistance (RPROBE): 7.2 ± 0.8 ohms (center to outer conductor).
• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 304 stainless steel (SST).
• Cable Specification: 75 Ω triaxial, FEP insulated (fluoroethylene propylene).
• Operating & Storage Temperature: -52°C to +177°C (-62°F to +351°F).
• Caution - Low Temp Seal: Exposure below -34°C (30°F) may harm the pressure seal.
• Probe Case Torque (Recommended): 21.1 N•m (187 in•lb).
• Probe Case Torque (Maximum): 63.3 N•m (560 in•lb).
• Connector Torque (Recommended): Finger tight.
• Connector Maximum Torque: 0.565 N•m (5 in•lb).
• Minimum Bend Radius: 25.4 mm (1.0 inch) – with or without armor.
• Maximum Thread Engagement Length: 24 mm for M16x1.5.

Installation & Mechanical Guidelines

• Use recommended torque of 21.1 N·m (187 in·lb) for M16x1.5 probe cases.
• Never exceed maximum torque of 63.3 N·m (560 in·lb) to avoid damage.
• Keep connector finger tight; maximum torque 0.565 N·m (5 in·lb) only.
• Do not bend the probe cable below 25.4 mm (1.0 inch) radius.
• Engage threads up to 24 mm maximum length for secure mounting.
• Target flat surface diameter must be at least 30.5 mm (1.2 inch).
• Minimum shaft diameter recommendation: 152 mm (6.0 inches).
• Avoid temperatures below -34°C (30°F) to protect the internal pressure seal.

Frequently Asked Questions (FAQ)

• Q: Is this 5m probe compatible with other proximitor sensors?
  A: No, the 5.0 meter probe works only with the five meter Proximitor Sensor from Bently Nevada.
• Q: What torque should I apply for the M16x1.5 probe case?
  A: Use recommended torque 21.1 N·m (187 in·lb). Maximum allowed is 63.3 N·m (560 in·lb).
• Q: What is the minimum target diameter for proper operation?
  A: For a flat surface, the minimum diameter is 30.5 mm (1.2 inches). For shafts, use at least 152 mm (6 inches).
• Q: Does the probe cable resist harsh fluids?
  A: Yes, the FluidLoc cable option and FEP insulation provide excellent fluid and chemical resistance.
• Q: Can I expose the probe to temperatures below -34°C?
  A: Doing so may cause premature failure of the pressure seal. Stay within -52°C to +177°C range but avoid prolonged -34°C exposure.
• Q: How do I connect the ClickLoc connector properly?
  A: Finger tighten only. Do not exceed 0.565 N·m (5 in·lb) maximum torque.
