330709-000-230-10-11-05 Bently Nevada 3300 XL 11 mm Probe

330709-000-230-10-11-05 Bently Nevada 3300 XL 11 mm Proximity Probe – Technical Overview

• Brand and Model: Bently Nevada 330709-000-230-10-11-05. This 3300 XL 11 mm probe comes with an M16 x 1.5 thread. The probe has no armor on its cable.
• Length Options: The unthreaded length option is 000 = 0 mm. Overall case length option 230 = 230 mm. Total length option 10 gives you 1.0 metre (3.3 feet).
• Connector and Cable: Option 11 provides a miniature coaxial ClickLoc connector. This connector includes a connector protector and FluidLoc cable. Agency approval option 05 means the probe has multiple approvals.
• Material and Build: The probe tip uses Polyphenylene sulfide (PPS). The probe case uses AISI 304 stainless steel (SST). This construction ensures excellent environmental tolerance.

Detailed Technical Specifications of the 3300 XL Probe

• Cross-talk Limitation: Minimum target size for a flat surface is 30.5 mm (1.2 in). Recommended minimum shaft diameter is 152 mm (6.0 in).
• Probe Case Torque (M16x1.5): Maximum rated torque is 63.3 N•m (560 in•lb). Recommended torque is 21.1 N•m (187 in•lb).
• Connector Torque: Finger tight is the recommended torque. Maximum torque is 0.565 N•m (5 in•lb).
• Minimum Bend Radius: 25.4 mm (1.0 in) with or without SST armor. Maximum thread engagement length is 24 mm.
• Temperature Range (Operating & Storage): -52°C to +177°C (-62°F to +351°F). Exposing below -34°C (30°F) may damage the pressure seal.
• Temperature Schedule (EPL Ga/Gc): T1: -55°C to +232°C, T2: -55°C to +177°C, T3: -55°C to +120°C, T4: -55°C to +80°C, T5: -55°C to +40°C.
• Temperature Schedule (EPL Dc): T280°C @ Ta: -55°C to +232°C, T225°C @ Ta: -55°C to +177°C, T170°C @ Ta: -55°C to +120°C, T130°C @ Ta: -55°C to +80°C, T105°C @ Ta: -55°C to +100°C, T90°C @ Ta: -55°C to +40°C.

Frequently Asked Questions (FAQ)

• Q: Is this probe brand new and original?
  A: Yes. We supply a brand new, original Bently Nevada 330709-000-230-10-11-05.
• Q: Do you have this model in stock?
  A: Yes, we have this 330709-000-230-10-11-05 in stock. We ship within 5 days after order confirmation.
• Q: What are the shipping methods?
  A: We use FedEx, UPS, and DHL for fast and reliable delivery worldwide.
• Q: Can I return the probe if needed?
  A: Yes. We support a 30-day return policy from the delivery date.
• Q: What happens if I exceed the maximum probe case torque?
  A: Exceeding 63.3 N•m (560 in•lb) may damage the M16x1.5 threads or the case.
• Q: Why does the temperature schedule list multiple T-class values?
  A: Different T-class values reflect safe operating limits for different ambient temperatures and explosive atmospheres (EPL Ga/Gc/Dc).
• Q: Can I use this probe with a smaller shaft than 152 mm?
  A: The recommended minimum shaft diameter is 152 mm (6.0 in) to avoid cross-talk errors.
